Siemens SINUMERIK 840D

5
Special Motion Commands 04.00
5.7 Extended measurin
g
function MEASA
,
MEAWA
,
MEAC
5
840D
NCU 571
840D
NCU 572
NCU 573
810D
CCU 2
840Di

Siemens AG 2000. All rights reserved
5-186
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
The following programming errors are detected and indicated
appropriately:
•
MEASA/MEAWA is programmed with MEAS/MEAW in the same
block
Example:
N01 MEAS=1 MEASA[X]=(1,1) G01 F100 POS[X]=100
•
MEASA/MEAWA with number of parameters <2 or >5
Example:
N01 MEAWA[X]=(1) G01 F100 POS[X]=100
•
MEASA/MEAWA with trigger event not equal to 1/ –1/ 2/ –2
Example:
N01 MEASA[B]=(1,1,3) B100
•
MEASA/MEAWA with invalid mode
Example:
N01 MEAWA[B]=(4,1) B100
•
MEASA/MEAWA with trigger event programmed twice
Example:
N01 MEASA[B]=(1,1,-1,2,-1) B100
•
MEASA/MEAWA and missing GEO axis
Example:
N01 MEASA[X]=(1,1) MEASA[Y]=(1,1) G01 X50 Y50 Z50 F100
•
Inconsistent measuring job with GEO axes
Example:
N01 MEASA[X]=(1,1) MEASA[Y]=(1,1) MEASA[Z]=(1,1,2) G01
X50 Y50 Z50 F100
GEO axis X/Y/Z
