Siemens SINUMERIK 840D

1
04.00 Flexible NC Programming
1.3 Arra
y
definition
1
840D
NCU 571
840D
NCU 572
NCU 573
FM-NC 810D 840Di

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
1-33
2. Options during program execution
ARRAY[n,m]= SET(value, value, value,...)
ARRAY[n,m]= SET(expression,
expression, expression,...)
•
Field elements are initialized as described above
for array definition.
•
Expressions may also be used here as
initialization values.
•
Initialization starts at the programmed array
indices. Values can also be assigned selectively
to subarrays.
Example:
Assignment of expressions
DEF INT ARRAY[5, 5]
ARRAY[0,0] = SET(1, 2, 3, 4, 5)
ARRAY[2,3] = SET(VARIABLE, 4*5.6)
The axis index is not processed for axis variables.
Example:
Initialization on one line
$MA_AX_VELO_LIMIT[1, AX1] = SET(1.1, 2.2, 3.3)
Corresponds to:
$MA_AX_VELO_LIMIT[1,AX1] = 1.1
$MA_AX_VELO_LIMIT[2,AX1] = 2.2
$MA_AX_VELO_LIMIT[3,AX1] = 3.3
