12.98 User Stock Removal Programs
14.2 Contour
p
re
p
aration: CONTPRON
14
840D
NCU 571
840D
NCU 572
NCU 573
FM-NC 810D 840Di

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
14-471
(9), (10) Center point coordinates of contour element, if it is a circle block.
(9) = abscissa, (10) = ordinate
Explanation of comment in columns
Always in table line 0:
1) Previous: Line n contains the contour end forwards
2) Following: Line n is the contour table end forwards
Once each within the contour elements forwards:
3) Previous: Contour start (forwards)
4) Following: Contour end (forwards)
Always in line contour table end (forwards) +1:
5) Previous: Number of relief cuts forwards
6) Following: Number of relief cuts backwards
Once each within the contour elements backwards:
7) Following: Contour end (backwards)
8) Previous: Contour start (backwards)
Always in last line of table:
9) Previous: Line n is the contour table start (backwards)
10) Following: Line n contains the contour start (backwards)
