Siemens SINUMERIK 840D

15
Tables 04.00
15.2 List of s
y
stem variables
15

Siemens AG 2000. All rights reserved
15-556
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
$P_SEARCH_PO
S
REAL $P_SEARCH_SPOS[n]
accum. last programmed spindle position or –path for SSL
Value range:from –100000000 to 100000000.
–100000000 to –0,001: possible spindle path in negative range
100000000 to 0,000: possible spindle path in positive range
Path and position definitions may be positive or negative and defined
up to three decimal places.
n: Positioning data must lie inside the modulo range
RW 5
.
3
$P_SEARCH_PO
SMODE
INT $P_SEARCH_SMODE[n]
accummulated last programmed position approach mode for SSL
0: DC (default)
1: AC
2: IC
3: DC
4: ACP
5: ACN
n: Spindle number, 0 – max.
RW 5
.
3
$P_SAUTOGEAR
BOOL $P_SAUTOGEAR[n]
programmed gear stage change
0: no automatic gear stage change
1: automatic gear stage change is active
R5
.
3
$P_SGEAR
INT $P_SGEAR[n]
last programmed/requested gear stage GS
1:1st gear stage is programmed/requested
2: 2. Requested gear stage
3: 3. Requested gear stage
4: 4. Requested gear stage
5: 5. Requested gear stage
n: Gear stage, 0 – max. gear stage
R5
.
3
$AC_SGEAR
INT $AC_SGEAR[n]
currently active gear stage
1: 1. Requested gear stage
2: 2. Requested gear stage
3: 3. Requested gear stage
4: 4. Requested gear stage
5: 5. Requested gear stage
n: Gear stage, 0 – max. gear stage
RS R 5
.
3
$P_SMODE
INT $P_SMODE[n]
Last programmed spindle mode:
0: No spindle or in other channel or PLC spindle
1: Speed control mode
2: Positioning mode
3: synchronized mode
4: Axis mode
n: Spindle number, 0 – max. spindle number
R3
$AC_SMODE
INT $AC_SMODE[n]
Spindle mode currently active
0: No spindle exists
1: Speed control mode
2: Positioning mode
3: synchronized mode
4: Axis mode
n: Spindle number, 0 – max. spindle number
RS R 3
