Programming example
1. Endless program
%_N_LOOP_MPF
LOOP
IF NOT $P_SEARCH
;No block search
G01 G90 X0 Z10 F1000
WHILE $AA_IM[X] <= 100
G1 G91 X10 F500
;Drilling pattern
Z–5 F100
Z5
ENDWHILE
Z10
ELSE
;Block search
MSG("No drilling during block search")
ENDIF
$A_OUT[1]=1
;Next drilling plate
G4 F2
ENDLOOP
M30
2. Production of a fixed quantity of parts
%_N_WKPCCOUNT_MPF
DEF INT WKPCCOUNT
FOR WKPCCOUNT = 0 TO 100
G01 …
ENDFOR
M30
