Siemens SIPART PS2 series User Manual

Overview parameter d
Parameter Function Parameter values Unit
d. STIC Monitoring of stiction (slipstick) with the following parameters:
d1.LIMIT Limit 0.1 ... 1.0 ... 100.0 %
d2.FACT1 Factor 1 0.1 ... 2.0 ... 100.0
d3.FACT2 Factor 2 0.1 ... 5.0 ... 100.0
d4.FACT3 Factor 3 0.1 ... 10.0 ... 100.0
Overview parameter E
Parameter Function Parameter values Unit
E. DEBA Monitoring of deadband with the following parameters:
E1.LEVL3 *) Threshold 0.1 ... 2.0 ... 10.0 %
*) The values are monitored in the range of '0.1' to '2.9'. Values between '3.0' and '10.0' are not
monitored.
Overview parameter F
Parameter Function Parameter values Unit
F. ZERO Monitoring of lower endstop with the following parameters:
F1.LEVL1 Threshold 1 0.1 ... 1.0 ... 10.0 %
F2.LEVL2 Threshold 2 0.1 ... 2.0 ... 10.0
F3.LEVL3 Threshold 3 0.1 ... 4.0 ... 10.0
Overview parameter G
Parameter Function Parameter values Unit
G. OPEN Monitoring of upper endstop with the following parameters:
G1.LEVL1 Threshold 1 0.1 ... 1.0 ... 10.0 %
G2.LEVL2 Threshold 2 0.1 ... 2.0 ... 10.0
G3.LEVL3 Threshold 3 0.1 ... 4.0 ... 10.0
Overview parameter H
Parameter Function Parameter values Unit
H. TMIN Monitoring of lower limit temperature with the following parameters:
H1.TUNIT Temperature unit °C °F °C/°F
H2.LEVL1 Threshold 1 -40 ... -25 ... 90 -40 ... 194
H3.LEVL2 Threshold 2 -40 ... -30 ... 90 -40 ... 194
H4.LEVL3 Threshold 3 -40 ... 90 -40 ... 194
Parameter assignment
8.3 Tabular overview of the parameters
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 11/2019, A5E00074631-AE 141

Siemens SIPART PS2 series Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Type	Electropneumatic
Input Signal	4-20 mA
Stroke Range	3 to 200 mm
Rotary Range	30 to 100°
Mounting	Linear or rotary actuators
Certifications	ATEX, IECEx, FM, CSA
