B.2.3 Connecting NCS to Analog Input Module (AIM)
Requirement
You need the Analog Input Module (AIM), article number 6DR4004-6F or -8F, for the electrical
connection of the accessory part "NCS sensor for non-contacting position measurement" to the
positioner. The positioner supplies auxiliary power to the NCS sensor via the option module.
Wiring diagram
;
;
JUHHQ
EODFN
EURZQ
\HOORZ
3RVLWLRQ7UDQVPLWWHU
'5)Q(['5)([
$QDORJ,QSXW0RGXOH
$,0
6
6
21
5HI
3RV
*1'
9FF
21
21
6
6
6
6
6
6
5HI
3RV
*1'
9FF
1&6'511
Positioner (open state) ⑦ Cable clamp
② Terminal Ref: Green ⑧ Screw F3x8
③ Terminal Pos: Black ⑨ Cable gland
④ Terminal GND: Brown ⑩ Four-pole NCS cable
⑤ Terminal Vcc: Yellow ⑪ Non Contacting Sensor (NCS)
⑥ Analog Input Module (AIM) ⑫ Cable shielding lug
Figure B-7 Example of connecting the NCS to the Analog Input Module (AIM)
External position detection
B.2 Non-Contacting Sensor
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 11/2019, A5E00074631-AE 281
