O3.FACT2 - Factor 2
Adjustment range: 0.1 ... 40.0
Purpose: Use this sub-parameter to set the factor for formation of threshold 2.
Set the factor in a range from '0.1' to '40.0'. The threshold is the
product of 'O1.LIMIT' and 'O3.FACT2'.
The threshold 2 message is displayed when threshold 2 is excee‐
ded. This message is only output if threshold 3 is not exceeded at
the same time. The process to activate and display this message is
described in the 'XDIAG' parameter.
Factory setting: 2.0
O4.FACT3 - Factor 3
Adjustment range: 0.1 ... 40.0
Purpose: Use this sub-parameter to set the factor for formation of threshold 3.
Set the factor in a range from '0.1' to '40.0'. The threshold is the
product of 'O1.LIMIT' and 'O4.FACT3'.
The threshold 3 message is displayed when threshold 3 is excee‐
ded. The process to activate and display this message is described
in the 'XDIAG' parameter.
Factory setting: 5.0
See also
Display of diagnostics values (Page 212)
8.4.3.12 Monitoring the position average value 'P.\\PAVG'
P. PAVG - Monitoring the position average value
Requirement: The '52.XDIAG' Activating for extended diagnostics (Page 162) pa‐
rameter is set to 'On1', 'On2' or 'On3'.
Possible settings: ● OFF
● On
Purpose: Use this parameter to activate the test to calculate and monitor the
average value of position. During the test, the average values of
position and reference are always compared at the end of a time
interval.
The current value is displayed in Diagnostic value '20.PAVG - Aver‐
age value of position' (Page 221). The positioner triggers a mes‐
sage if the current average value of position undershoots one of the
three thresholds.
Factory setting: OFF
Parameter assignment
8.4 Description of parameters
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 11/2019, A5E00074631-AE 185
