Siemens SIPART PS2 series User Manual

6DR4004-.N.10 6DR4004-.N.40
1 2 Tensioning ring
4 4 Hexagon nut M6
2 2 Hex socket head screw M6x25
- 2 Hex socket head screw M3x12
1 1 Non-contacting sensor Cable lengths as ordered
1 1 Self-tapping screw for polycar‐
bonate enclosure
F3x8
1 1 Sealing For cable bushings
1 1 Plugs For closing the sealing insert
1 1 Cable clamp
1 1 DVD with documentation
See also
Mounting the NCS (Page 273)
B.2.7.2 Scope of delivery of NCS for linear actuators up to 14 mm (0.55 inch) .
Linear actuator with a stroke range up to 14 mm (0.55 inch) 6DR4004-.N.20
Quantity Designation Notes
1 Magnet
5 Washer 6
2 Hex socket head screw M6x12
4 Hexagon nut M6
2 Hex socket head screw M6x25
1 Non-contacting sensor Cable lengths as ordered
1 Screw F3x8
1 Sealing For cable bushings
1 Plugs For closing the sealing insert
1 Cable clamp
1 DVD with documentation
See also
Mounting the NCS (Page 273)
External position detection
B.2 Non-Contacting Sensor
SIPART PS2 with 4 to 20 mA/HART
286 Operating Instructions, 11/2019, A5E00074631-AE

Siemens SIPART PS2 series Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Type	Electropneumatic
Input Signal	4-20 mA
Stroke Range	3 to 200 mm
Rotary Range	30 to 100°
Mounting	Linear or rotary actuators
Certifications	ATEX, IECEx, FM, CSA
