B.2.4.2 Initialization of part-turn actuators
Procedure
1. For part-turn actuators operating in standard control direction, set parameter "1.YFCT" to
"ncSt", or to "-ncSt" in case of inverse control direction.
2. Launch initialization as usual with "INITA".
B.2.4.3 Initializing linear actuators with a stroke range up to 14 mm (0.55 inch)
Requirements
1. Set the "1.YFCT" parameter of the positioner to "ncSL" or - with inverse control direction -
to "-ncSL".
2. Launch initialization as usual with "INITA".
B.2.4.4 Initializing linear actuators with a stroke range > 14 mm (0.55 inch)
Note
Parameter values "ncSLL" and "-ncLL" are only available for devices of the 6DR5... series and
only with the firmware version > C4. Set the value to 90° on devices of the 6DR5... series with
firmware version < C5 (YAGL). This setting is also necessary for devices of the 6DR4... series.
Resultant non-linearity can be corrected by means of the programmable characteristic by
setting the parameter value from "SFCT" to "FrEE" and adapting the interpolation points.
Requirements
1. Set the "1.YFCT" parameter of the positioner to "ncSLL" or - with inverse control direction
- to "-ncLL".
2. Launch initialization as usual with "INITA".
B.2.5 Technical specifications NCS
Additional modules Without Ex protection With Ex protection
Ex "ia"
With explosion protection
Ex "ic", "ec"
Travel range
● Linear actuator 6DR4004-6/8N.20
3 to 14 mm (0.12 to 0.55")
● Linear actuator 6DR4004-6/8N.30
10 to 130 mm (0.39 to 5.12"); up to 200 mm (7.87") on request
● Part-turn actuator
30 to 100°
External position detection
B.2 Non-Contacting Sensor
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 11/2019, A5E00074631-AE 283

Siemens SIPART PS2 series Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Type	Electropneumatic
Input Signal	4-20 mA
Stroke Range	3 to 200 mm
Rotary Range	30 to 100°
Mounting	Linear or rotary actuators
Certifications	ATEX, IECEx, FM, CSA
