Additional modules Without Ex protection With Ex protection
Ex "ia"
With explosion protection
Ex "ic", "ec"
Linearity (after corrections made by
positioner)
± 1 %
Hysteresis ± 0.2 %
Temperature influence (range: rota‐
tion angle 120° or stroke 14 mm)
≤ 0.1 %/10 K (≤ 0.1 %/18 °F) for -20 to +90 °C (-4 to +194 °F)
≤ 0.2%/10 K (≤ 0.2%/18 °F) for -40 to -20 °C (-40 to -4 °F)
Climate class According to IEC/EN 60721-3
● Storage
1K5, but -40 to +90 °C (-40 to +194 °F)
● Transport
2K4, but -40 to +90 °C (-40 to +194 °F)
Vibration resistance
● Harmonic oscillations
(sine) according to IEC 60068-2-6
3.5 mm (0.14"), 2 to 27 Hz, 3 cycles/axis
98.1 m/s² (321.84 ft/s²), 27 to 300 Hz, 3 cycles/axis
● Bumping according to IEC
60068-2-29
300 m/s
2
(984 ft/s
2
), 6 ms, 4000 shocks/axis
Torque for cable gland nut made of Plastic Metal Stainless steel
2.5 Nm (1.8 ft lb) 4.2 Nm (3.1 ft lb) 4.2 Nm (3.1 ft lb)
Torque of hexagon socket-head
screw M6x12 (shaft end or mounting
bracket)
4 Nm (3 ft lb)
Torque of hexagon socket head screw
M6x25 (mounting console or mount‐
ing plate)
4 Nm (3 ft lb)
Torque of hexagon socket head screw
M3x12 (clamping ring)
1 Nm (0.7 ft lb)
Degree of protection IP68 / type 4X
For connecting to circuits with the fol‐
lowing peak values
- U
i
= 5 V
I
i
= 160 mA
P
i
= 120 mW
U
i
= 5 V
Effective internal capacitance - C
i
=
1)
C
i
=
1)
Effective internal inductance - L
i
=
2)
L
i
=
2)
1)
C
i
= 110 nF + 110 nF per meter of connecting cable
2)
L
i
= 270 µH + 6.53 µH per meter of connecting cable
External position detection
B.2 Non-Contacting Sensor
SIPART PS2 with 4 to 20 mA/HART
284 Operating Instructions, 11/2019, A5E00074631-AE
