Figure F-3 Grounding concept of 19" slide-in module 4 to 20 mA version
Notes on the individual connection points:
The cable shield is not connected to the positioner 6DR5910.
The positioner 6DR5910 is connected via the mechanical assembly to Ground 2 ,
see Installing/mounting (Page 37). Section Basic safety instructions (Page 75) de‐
scribes how to ground the enclosure.
Each field distributor is grounded. The cable shields in the field distributor are not
grounded. The cable shields are interconnected.
The cable shields on the 19" slide-in module are connected to the field distributor.
The 19" slide-in module is connected to Ground 1.
The cable shields on the control system are not connected to ground.
F.2.2.2 Electrical connection of 19" slide-in module 4 to 20 mA
Requirement
You have read sections Connection (Page 75) and Grounding concept of 19" slide-in module
4 to 20 mA (Page 312).
Positioner with remote control electronics
F.2 19" slide-in module
SIPART PS2 with 4 to 20 mA/HART
314 Operating Instructions, 11/2019, A5E00074631-AE
