Siemens SIPART PS2 series User Manual

Positioner and option modules Temperature class T4 Temperature class T6
Option modules
● Non-Contacting Sensor (NCS)
6DR4004-6N
-40 °C ≤Ta ≤ +90 °C -40 °C ≤Ta ≤ +70 °C
● Position Transmitter (Potentiometer)
6DR4004-1ES
-40 °C ≤Ta ≤ +90 °C -40 °C ≤Ta ≤ +60 °C
● Position Transmitter (NCS)
6DR4004-2ES
-40 °C ≤Ta ≤ +90 °C -40 °C ≤Ta ≤ +50 °C
● Position Transmitter (NCS, ILS)
6DR4004-3ES
● Position Transmitter (NCS, MLS)
6DR4004-4ES
12.6 Electrical data
Basic electronics
without explosion
protection
Basic electronics
with explosion pro‐
tection Ex "db"
Basic electronics
with explosion pro‐
tection Ex "ia", "db ia"
Basic electronics
with explosion pro‐
tection Ex "ic", "ec",
"tb"
Current input I
W
● Rated signal range
4 ... 20 mA
● Test voltage
840 V DC, 1 s
● Digital input DI1 (terminals
9/10; galvanically connec‐
ted to basic device)
Suitable only for floating contact; max. contact load
< 5 μA with 3 V
2-wire connection
6DR50.. and 6DR53.. 4 ... 20 mA
6DR51.. and 6DR52.. HART
Current to maintain the auxiliary
power
≥ 3.6 mA
Required load voltage U
B
(cor‐
responds to Ω at 20 mA)
● 4 to 20 mA 6DR50..
Typical 6.36 V (= 318 Ω) 6.36 V (= 318 Ω) 7.8 V (= 390 Ω) 7.8 V (= 390 Ω)
Max. 6.48 V (= 324 Ω) 6.48 V (= 324 Ω) 8.3 V (= 415 Ω) 8.3 V (= 415 Ω)
● 4 to 20 mA 6DR53..
Typical 7.9 V (= 395 Ω) - - -
Max. 8.4 V (= 420 Ω) - - -
● HART 6DR51..
Typical 6.6 V (= 330 Ω) 6.6 V (= 330 Ω) - -
Max. 6.72 V (= 336 Ω) 6.72 V (= 336 Ω) - -
HART 6DR52..
Technical data
12.6 Electrical data
SIPART PS2 with 4 to 20 mA/HART
246 Operating Instructions, 11/2019, A5E00074631-AE

Siemens SIPART PS2 series Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Type	Electropneumatic
Input Signal	4-20 mA
Stroke Range	3 to 200 mm
Rotary Range	30 to 100°
Mounting	Linear or rotary actuators
Certifications	ATEX, IECEx, FM, CSA
