Note
Height adjustment of the positioner
When you fasten the positioner on the yoke, the following applies to its height adjustment:
1. Set the height of the positioner in such a way that the horizontal lever position is near the
center of the stroke.
2. Orient yourself by the lever scale of the actuator.
3. If symmetrical mounting is not possible, you must always ensure that the horizontal lever
position is maintained within the range of stroke.
4.3 Mounting to part-turn actuator
Requirements
You require an actuator-specific VDI/VDE 3845 mount to install the positioner on a part-turn
actuator. Because of the high weight of the version in the flameproof stainless steel enclosure
6DR5..6, you should select a particularly stable mount.
Procedure
"Part-turn actuator" mounting kit 6DR4004–8D
Sr.
no. *
)
Quan
tity
Designation Note
① 1 Coupling wheel Installation on positioner shaft
② 1 Carrier Installing on the actuator shaft
③ 1 Multiple plate Display of the position, consisting of scale ⑤ and pointer mark ⑥
④ 8 Scale Different divisions
⑤ 2 Pointer mark Reference point for scale
⑥ Mounting console Actuator-specific, VDI/VDE 3845
⑦ 4 Hexagon bolt M6x12 DIN 933, torque see the section "Technical specifications > Construction
(Page 240)"
⑧ 4 Lock washer S6
⑨ 1 Socket cap screw M6x16 DIN 84
⑩ 1 Washer 6.4 DIN 125
⑪ 1 Hex socket-head
screw
For coupling wheel
1 Machinist's wrench For hexagon socket-head screw ⑪
*)
The serial numbers refer to the images in the description of the steps below.
Installing/mounting
4.3 Mounting to part-turn actuator
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 11/2019, A5E00074631-AE 45
