No. Short desig‐
nation
Meaning Representable di‐
agnostics values
Unit Properties
23 IMPUP Pulse length up 6 ... 160 ms ④
24 IMPDN Pulse length down 6 ... 160 ms ④
25 PAUTP Pulse pause 2 ... 28 ... 320 ms ④
26 DBUP Deadband up 0.1 ... 10.0 % ②
27 DBDN Deadband down 0.1 ... 10.0 % ②
28 SSUP Slow step zone up 0.1 ... 10.0 ...
100.0
% ④
29 SSDN Slow step zone down 0.1 ... 10.0 ...
100.0
% ④
30 TEMP Current temperature -50 ... 100
-58 ... 212
°C
°F
②
31 TMIN Minimum temperature (min/max pointer) -50 ... 100
-58 ... 212
°C
°F
②
32 TMAX Maximum temperature (min/max pointer) -50 ... 100
-58 ... 212
°C
°F
②
33 T1 Number of operating hours in temperature range 1 0 ... 4.29E9 Hours ②
34 T2 Number of operating hours in temperature range 2 0 ... 4.29E9 Hours ②
35 T3 Number of operating hours in temperature range 3 0 ... 4.29E9 Hours ②
36 T4 Number of operating hours in temperature range 4 0 ... 4.29E9 Hours ②
37 T5 Number of operating hours in temperature range 5 0 ... 4.29E9 Hours ②
38 T6 Number of operating hours in temperature range 6 0 ... 4.29E9 Hours ②
39 T7 Number of operating hours in temperature range 7 0 ... 4.29E9 Hours ②
40 T8 Number of operating hours in temperature range 8 0 ... 4.29E9 Hours ②
41 T9 Number of operating hours in temperature range 9 0 ... 4.29E9 Hours ②
42 VENT1 Number of switching cycles pneumatic block, Valve 1 0 ... 4.29E9 - ②
43 VENT2 Number of switching cycles pneumatic block, Valve 2 0 ... 4.29E9 - ②
44 VEN1R Number of switching cycles pneumatic block, Valve 1,
resettable
0 ... 4.29E9 - ①
45 VEN2R Number of switching cycles pneumatic block, Valve 2,
resettable
0 ... 4.29E9 - ①
46 STORE Save the current values as 'last maintenance'
(press button for 5 seconds)
- - ③
47 PRUP Prediction up 1 ... 40 - ④
48 PRDN Prediction down 1 ... 40 - ④
49 WT00 Number of operating hours in the travel range WT00 0 ... 4.29E9 Hours ①
50 WT05 Number of operating hours in the travel range WT05 0 ... 4.29E9 Hours ①
51 WT10 Number of operating hours in the travel range WT10 0 ... 4.29E9 Hours ①
52 WT30 Number of operating hours in the travel range WT30 0 ... 4.29E9 Hours ①
53 WT50 Number of operating hours in the travel range WT50 0 ... 4.29E9 Hours ①
54 WT70 Number of operating hours in the travel range WT70 0 ... 4.29E9 Hours ①
55 WT90 Number of operating hours in the travel range WT90 0 ... 4.29E9 Hours ①
56 WT95 Number of operating hours in the travel range WT95 0 ... 4.29E9 Hours ①
57 LKPUL Length of the leakage compensation pulse -256 ... 0 ... 254 ms ②
58 LKPER Period of the leakage compensation pulse 0.00 ... 600.00 s ②
Diagnostics and troubleshooting
11.2 Diagnostics
SIPART PS2 with 4 to 20 mA/HART
214 Operating Instructions, 11/2019, A5E00074631-AE
