① Single-acting positioner in flameproof aluminum enclosure
② Pressure gauge block, single-acting
③ Yoke / actuator yoke
④ Actuator
Figure 3-3 Positioner in flameproof aluminum enclosure attached to linear actuator
① Part-turn actuator
② Double-acting positioner in flameproof aluminum enclosure
③ Pressure gauge block, double-acting
Figure 3-4 Positioner in flameproof aluminum enclosure attached to part-turn actuator
Description
3.2 Structure
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 11/2019, A5E00074631-AE 25
