Siemens SIPART PS2 series User Manual

Position Transmitter (NCS, MLS) 6DR4004-4ES
Without explosion protec‐
tion
With explosion protection
Ex "ia", "db ia", "ic"
With explosion protection
Ex "ec", "tb"
Degree of protection provided by en‐
closure
IP66 according to IEC/EN 60529; type 4X according to UL 50E
NCS module (NCS) 6DR4004-5L 6DR4004-5LE 6DR4004-5LE
● For connecting to circuits with the
following peak values
U
i
≤ 5 V
I
i
≤ 160 mA
P
i
≤ 120 mW
U
i
≤ 5 V
I
i
≤ 160 mA
● Effective internal capacitance
C
i
= 110 nF + 690 pF/m
Connecting cable
-
● Effective internal inductance
L
i
= 270 μH + 6,53 μH/m
Connecting cable
-
Mechanic Limit Switches (MLS) 6DR4004-8K 6DR4004-6K 6DR4004-6K
2 limit contacts
● Digital output (switching contact) A1: Terminals 41 and 42
● Digital output (switching contact) A2: Terminals 51 and 52
● Max. switching current AC/DC
4 A - -
● For connecting to circuits with the
following peak values
- U
i
≤ 30 V
I
i
≤ 100 mA
P
i
≤ 750 mW
U
n
≤ 30 V
I
n
≤ 100 mA
Effective internal capacitance - C
i
= negligibly small -
Effective internal inductance - L
i
= negligibly small -
● Max. switching voltage AC/DC
250 V/24 V DC 30 V DC 30 V
1 fault message output
● Digital output: Terminals 31 and 32
● Connection
On switching amplifier according to EN 60947-5-6: (NAMUR), U
Aux
= 8.2 V, Ri = 1 kΩ)
● Signal state High
(not triggered)
R = 1.1 kΩ > 2.1 mA > 2.1 mA
● Signal state Low (triggered)
R = 10 kΩ < 1.2 mA < 1.2 mA
● Auxiliary power
U
Aux
≤ DC 35 V
I ≤ 20 mA
- -
● Connecting to circuits with the fol‐
lowing peak values
- U
i
≤ 15 V
I
i
≤ 25 mA
P
i
≤ 64 mW
U
n
≤ 15 V
I
n
≤ 25 mA
Effective internal capacitance - Ci = 5.2 nF Ci = 5.2 nF
Effective internal inductance - L
i
= negligibly small
Galvanic isolation The 3 digital outputs are galvanically isolated from the basic unit
Test voltage 3150 V DC, 2 s
Rated condition height Max. 2 000 m above sea
level. Use a suitable power
supply at an altitude of
more than 2 000 m above
sea level.
- -
External position detection
B.3 External position detection
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 11/2019, A5E00074631-AE 293

Siemens SIPART PS2 series Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Type	Electropneumatic
Input Signal	4-20 mA
Stroke Range	3 to 200 mm
Rotary Range	30 to 100°
Mounting	Linear or rotary actuators
Certifications	ATEX, IECEx, FM, CSA
