Construction
Weight Approx. 1.8 kg
Material body 19" slide-in module, 2HM, aluminum
Number of channels, basic electronics: 3
Climate class According to IEC/EN 60721-3
● Storage
-25°C to 80°C, 75% at 25°C, without condensation
● Transport
-25°C to 80°C, 75% at 25°C, without condensation
● Operation
0°C to 50°C, 75% at 25°C, without condensation
Electrical data
Electrical connection 9-pin Sub-D plug
15-pin Sub-D female connector
Current input I
W
● Rated signal range
4 to 20 mA
● Current to maintain the auxiliary power
≥ 3.6 mA
2-wire connection
● Current to maintain the auxiliary power
≥ 3.6 mA
● Required load voltage U
B
(corresponds to Ω at 20 mA)
6.4 V (= 320 Ω)
● Static destruction limit
± 40 mA
Technical specifications for the controller unit is available at Controller (Page 242).
Technical specifications of the Analog Output Module (AOM) are available at Analog Output
Module (AOM) 6DR4004-6J / -8J (Page 251).
Cable data (minimum requirements)
Cable length ≤ 130 m
Capacity wire / wire ≤ 150 nF/km
Capacity wire / shield ≤ 200 nF/km
Inductance ≤ 1 mH/km
Copper resistance ≤ 100 Ω/km
Insulation conductance ≥ 0.5 x 10
7
S/km
Ambient temperature -30 ... +80 °C
Number of poles
● Cable to the control system (min/max)
4 or 9
● Cable to the positioner 6DR5910
8 or 15
Connection
● Cable to the control system (min/max)
9-pin Sub-D female connector
● Cable to the positioner 6DR5910
15-pin Sub-D male connector
Positioner with remote control electronics
F.2 19" slide-in module
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 11/2019, A5E00074631-AE 317
