Siemens SIPROTEC 4 7SD80 User Manual

Addr. Parameter Setting Options Default Setting Comments
3702 59-1-Vph PICKUP 1.0 .. 170.0 V 85.0 V 59-1 Pickup Overvoltage (phase-
ground)
3703 59-1-Vph DELAY 0.00 .. 100.00 sec 2.00 sec 59-1 Time Delay
3704 59-2-Vph PICKUP 1.0 .. 170.0 V 100.0 V 59-2 Pickup Overvoltage (phase-
ground)
3705 59-2-Vph DELAY 0.00 .. 100.00 sec 1.00 sec 59-2 Time Delay
3709A 59-Vph RESET 0.30 .. 0.99 0.98 Reset ratio
3711 59-Vph-ph Mode OFF
Alarm Only
ON
V>Alarm V>>Trip
OFF Operating mode Vph-ph over-
voltage prot.
3712 59-1-Vpp PICKUP 2.0 .. 220.0 V 150.0 V 59-1 Pickup Overvoltage (phase-
phase)
3713 59-1-Vpp DELAY 0.00 .. 100.00 sec 2.00 sec 59-1 Time Delay
3714 59-2-Vpp PICKUP 2.0 .. 220.0 V 175.0 V 59-2 Pickup Overvoltage (phase-
phase)
3715 59-2-Vpp DELAY 0.00 .. 100.00 sec 1.00 sec 59-2 Time Delay
3719A 59-Vpp RESET 0.30 .. 0.99 0.98 Reset ratio
3721 59G-3V0 (or Vx) OFF
Alarm Only
ON
V>Alarm V>>Trip
OFF Operating mode 3V0 overvoltage
3722 59G-1-3V0PICKUP 1.0 .. 220.0 V 30.0 V 59G-1 Pickup 3V0 (zero seq.)
3723 59G-1-3V0 DELAY 0.00 .. 100.00 sec 2.00 sec 59G-1 Time Delay
3724 59G-2-3V0PICKUP 1.0 .. 220.0 V 50.0 V 59G-2 Pickup 3V0 (zero seq.)
3725 59G-2-3V0 DELAY 0.00 .. 100.00 sec 1.00 sec 59G-2 Time Delay
3728A 59G-3Vo Stabil. ON
OFF
ON 59G: Stabilization 3Vo-Measure-
ment
3729A 59G RESET 0.30 .. 0.99 0.95 Reset ratio
3731 59-V1 Mode OFF
Alarm Only
ON
V>Alarm V>>Trip
OFF Operating mode V1 overvoltage
prot.
3732 59-1-V1 PICKUP 2.0 .. 220.0 V 150.0 V 59-1 Pickup Overvoltage (pos.
seq.)
3733 59-1-V1 DELAY 0.00 .. 100.00 sec 2.00 sec 59-1 Time Delay
3734 59-2-V1 PICKUP 2.0 .. 220.0 V 175.0 V 59-2 Pickup Overvoltage (pos.
seq.)
3735 59-2-V1 DELAY 0.00 .. 100.00 sec 1.00 sec 59-2 Time Delay
3739A 59-V1 RESET 0.30 .. 0.99 0.98 Reset ratio
3741 59-V2 Mode OFF
Alarm Only
ON
V>Alarm V>>Trip
OFF Operating mode V2 overvoltage
prot.
3742 59-1-V2 PICKUP 2.0 .. 220.0 V 30.0 V 59-1 Pickup Overvoltage (neg.
seq.)
3743 59-1-V2 DELAY 0.00 .. 100.00 sec 2.00 sec 59-1 Time Delay
3744 59-2-V2 PICKUP 2.0 .. 220.0 V 50.0 V 59-2 Pickup Overvoltage (neg.
seq.)
Functions
2.8 Undervoltage and Overvoltage Protection (optional) 27/59
118 SIPROTEC 4, 7SD80, Manual
E50417-G1100-C474-A2, Edition 02.2018
