Siemens SIPROTEC 4 7SD80 User Manual

Setting Notes
Retrieving Parameters
The SIPROTEC 4 System Description describes in detail how to read out the statistical counters via the device
front panel or DIGSI. The values are added up in direction of the protected object provided the direction was
set as “forward” (address 201).
Information List
No. Information Type of
Informa-
tion
Comments
- Meter res IntSP_Ev Reset meter
888 Wp(puls) PMV Pulsed Energy Wp (active)
889 Wq(puls) PMV Pulsed Energy Wq (reactive)
916 WpΔ= - Increment of active energy
917 WqΔ= - Increment of reactive energy
924 Wp+= MVMV Wp Forward
925 Wq+= MVMV Wq Forward
928 Wp-= MVMV Wp Reverse
929 Wq-= MVMV Wq Reverse
2.17.9.2
2.17.9.3
Functions
2.17 Auxiliary Functions
192 SIPROTEC 4, 7SD80, Manual
E50417-G1100-C474-A2, Edition 02.2018
