Ordering Information 7SD80 V4.7
Line Differential
Protection
6 7 8 9 10 11 12 13 14 15 16 Supplement
7 S D 8 0 – – F +
Measuring inputs, BO/BI, protection interface Pos. 6
1/6 19" housing; 4 x I, 3 BI, 5 BO (2 changeover contacts), 1 life status contact,
Protection interface optical fiber for monomode (24 km) (14.9 mi.)/multimode fiber (4 km) (2.5 mi.), LC
duplex connector
1
1/6 19" housing; 4 x I, 7 BI, 8 BO (2 changeover contacts), 1 life status contact,
Protection interface optical fiber for monomode (24 km) (14.9 mi.)/multimode fiber (4 km) (2.5 mi.), LC
duplex connector
2
1/6 19" housing; 4 x I, 5 BI, 8 BO (2 changeover contacts), 1 life status contact,
Protection interface copper (2-wire connection, twisted)
3
1/6 19" housing; 4 x I, 3 x V, BI, 5 BO (2 changeover contacts), 1 life status contact,
Protection interface optical fiber for monomode (24 km)/multimode fiber (4 km), LC duplex connector
5
1/6 19" housing; 4 x I, 3 x V, 7 BI, 8 BO (2 changeover contacts), 1 life status contact,
Protection interface optical fiber for monomode (24 km)/multimode fiber (4 km), LC duplex connector
6
1/6 19" housing; 4 x I, 3 x V, 5 BI, 8 BO (2 changeover contacts), 1 life status contact,
Protection interface copper (2-wire connection, twisted)
7
Measuring inputs, default settings Pos. 7
Ι
ph
= 1 A / 5 A , Ι
N
= 1 A / 5 A
1
Ι
ph
= 1 A, Ι
Ns
(sensitive) = 0.001 A to 1.6 A / 0.005 A to 8 A
2
Auxiliary voltage (power supply) Pos. 8
DC 24 V / 48 V 1
DC 60 V / 110 V/ 125 V/ 220 V/ 250 V, AC 115 V, AC 230 V 5
Construction Pos. 9
Surface-mounted housing, screw-type terminals B
Flush mounting case, screw-type terminals E
Region-specific language default settings and function versions Pos. 10
Region DE, IEC, language German (language can be changed) standard face plate A
Region world, IEC/ANSI, language English (language can be changed), standard face plate B
Region US, ANSI, language US - English (language can be changed), US face plate C
Port B (bottom side of device, front) Pos. 11
not equipped 0
IEC60870-5-103 or DIGSI4/modem or time synchronization input, electrical RS232 1
IEC60870-5-103 or DIGSI4/modem or time synchronization input, electrical RS485 2
IEC60870-5-103 or DIGSI4/modem, optical 820 nm, ST connector 3
For further interface options, see the following additional information 9
Additional information for additional ports (bottom side of device, front, port B) Zusatz
Profibus DP Slave, electrical RS485 + L 0 A
Profibus DP Slave, optical, double ring, ST connector + L 0 B
Modbus, electrical RS485 + L 0 D
Modbus, 820 nm, optical, ST connector + L 0 E
DNP3.0, electrical RS485 + L 0 G
A.1
Ordering Information and Accessories
A.1 Ordering Information 7SD80 V4.7
300 SIPROTEC 4, 7SD80, Manual
E50417-G1100-C474-A2, Edition 02.2018
