Additional information for additional ports (bottom side of device, front, port B) Zusatz
DNP3.0, optical, 820 nm, ST connector + L 0 H
IEC 60870-5-103, redundant, electrical RS485, RJ45 connector + L 0 P
IEC61850, 100Mbit Ethernet, 2 electrical ports, RJ45 connector + L 0 R
IEC61850, 100Mbit Ethernet, 2 optical ports, LC-duplex- connector + L 0 S
Converter Order number Use
SIEMENS OLM
1)
6GK1502–2CB10 for single ring
SIEMENS OLM
1)
6GK1502–3CB10 for double ring
1)
The converter requires an operating voltage of 24 VDC. If the available operating voltage is > 24 VDC the additional
power supply 7XV5810–0BA00 is required.
Additional communication interfaces for port A (bottom side of device, rear) Pos. 12
no additional
1)
0
Redundant optical fiber protection interface to 2-wire protection interface
Protection interface optical fiber for monomode (24 km) (14.9 mi.)/multimode fiber (4 km) (2.5 mi.), LC
duplex connector
2)
7
1)
Already equipped with optical fiber protection interface if MLFB pos. 6 = 1,2,5 or 6
2)
Deliverable only in combination with 6th position = 3 or 7
Measurement / Fault Recording Pos. 13
With fault recording 1
With fault recording, average values, min/max values 3
Protection functions Pos. 15
ANSI-Nr Description
Basic design (included in all versions) A
87L/87N L
Line differential protection (phase comparison and 3I0 differential protection)
1)
Inrush current detection
50 TD/51 Overcurrent protection phase 50-1, 50-2, 50-3, 51
50N TD/51N Overcurrent protection ground 50N-1, 50N-2, 50N-3, 51N
49 Thermal overload protection (49)
74TC Trip circuit supervision
50BF Circuit-breaker failure protection
86 Lock out
Circuit breaker transfer trip
External trip initiation
Cold load pickup (dynamic setting changes)
Monitoring functions
Circuit breaker test
Circuit breaker control
Flexible protection functions from current, voltage, power
2)
27/59
Undervoltage/overvoltage 27, 59
2)
81 U/O
Underfrequency / overfrequency
2)
Basic design + directional overcurrent protection phase and directional ground fault protection
1)
3)
B
67
Overcurrent protection, directional phase ∠(V, Ι) 67-1, 67-2, 67-TOC
67N
Ground fault protection, directional ∠(V, Ι) 67N-1, 67N-2, 67N-TOC
Basic design + ground fault differential protection in resonant-grounded/isolated systems
3)
4)
C
87Ns L Ground fault differential protection in resonant-grounded/isolated systems
Ordering Information and Accessories
A.1 Ordering Information 7SD80 V4.7
SIPROTEC 4, 7SD80, Manual 301
E50417-G1100-C474-A2, Edition 02.2018
