Characteristic Curves for the 50N Element
During configuration of the scope of functions at address 126, the available characteristics were determined.
Depending on the selection made there, only the parameters associated with this characteristic curve are
accessible.
The inverse time elements enable the user to select different characteristic curves. Address 126 allows you to
specify whether you work with IEC characteristics 50(N) 51(N) IEC or ANSI characteristics 50(N)
51(N)ANSI).
Bei den stromabhängigen Stufen können verschiedene Kennlinien gewählt werden. Unter Adresse 126 stellen
Sie ein, ob Sie mit IEC-Kennlinien (50(N) 51(N) IEC) oder ANSI-Kennlinien arbeiten (50(N) 51(N)ANSI).
If you work with IEC characteristics, you can select the following setting options at address 2642:
•
Normal Inverse
•
Very Inverse
•
Extremely Inv.
•
LongTimeInverse
If you work with ANSI characteristics, you can select the following setting options at address 2643:
•
Inverse
•
Short Inverse
•
Long Inverse
•
Moderately Inv.
•
Very Inverse
•
Extremely Inv.
•
Definite Inv.
The characteristics and equations they are based on are listed in the “Technical Data”. They apply for direc-
tional and non-directional elements alike.
Settings
Addresses which have an appended “A” can only be changed with DIGSI, under “Additional Settings”.
The table indicates region-specific default settings. Column C (configuration) indicates the corresponding
secondary nominal current of the current transformer.
Addr.
Parameter C Setting Options Default Setting Comments
2603A 67N dir. meas. V0/I0 or V2/I2
with V0/I0
with V2/I2
V0/I0 or V2/I2 67N, Measurement of
direction
2610 Op.Mode50(N)-B1 ON
Only Emer. prot
OFF
OFF Operating Mode 50(N)-B1
2610 Op.Mode67(N)-B1 ON
Only Emer. prot
OFF
OFF Operating Mode 67(N)-B1
2611 67(N)-B1 Dir. Non-Directional
Forward
Reverse
Non-Directional 67(N)-B1 Direction
2612 67(N)-B1 on FFM Non-Directional
BLOCKED
BLOCKED 67(N)-B1 Direct. stage on
Fuse Failure
2613 50-B1 PICKUP 1A 0.10 .. 25.00 A; ∞ 2.00 A 50-B1 Pickup
5A 0.50 .. 125.00 A; ∞ 10.00 A
2.4.5
Functions
2.4 Backup overcurrent
SIPROTEC 4, 7SD80, Manual 85
E50417-G1100-C474-A2, Edition 02.2018
