Addr. Parameter Setting Options Default Setting Comments
206 CT SECONDARY 1A
5A
1A CT Rated Secondary Current
207 SystemStarpoint Grounded
Peterson-C.Gnd.
Isolated
Grounded System Starpoint is
220 I4 transformer Not connected
In prot. line
In prot. line I4 current transformer is
221 I4/Iph CT 0.010 .. 5.000 1.000 Matching ratio I4/Iph for CT's
230 Rated Frequency 50 Hz
60 Hz
50 Hz Rated Frequency
240A TMin TRIP CMD 0.02 .. 30.00 sec 0.10 sec Minimum TRIP Command Duration
241A TMax CLOSE CMD 0.01 .. 30.00 sec 1.00 sec Maximum Close Command Dura-
tion
242 T-CBtest-dead 0.00 .. 30.00 sec 0.10 sec Dead Time for CB test-autoreclo-
sure
260 Threshold BI 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 1
261 Threshold BI 2 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 2
262 Threshold BI 3 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 3
263 Threshold BI 4 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 4
264 Threshold BI 5 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 5
265 Threshold BI 6 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 6
266 Threshold BI 7 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 7
Oscillographic Fault Records
The 7SD80 multifunctional protection with control is equipped with a fault record memory. The instantaneous
values of the measured values
i
A
, i
B
, i
C
, i
E
, i
EE
und v
A
, v
B
, v
C
, 3Ι0
diff
, 3Ι0
rest
(voltages in accordance with connection) are sampled at intervals of 1.0 ms (for 50 Hz) and stored in a
revolving buffer (20 samples per cycle). In the event of a fault, the data is stored for a set period of time, but
not for more than 5 seconds. Up to 8 fault events can be recorded in this buffer. The fault record memory is
automatically updated with every new fault so that there is no acknowledgment for previously recorded faults
required. In addition to protection pickup, the recording of the fault event data can also be started via a binary
input or via the serial interface.
2.1.4
Functions
2.1 General
SIPROTEC 4, 7SD80, Manual 39
E50417-G1100-C474-A2, Edition 02.2018
