Renaming Messages, Checking Configurations
After parameterization of a flexible function, the following steps should be noted:
•
Open matrix in DIGSI
•
Rename the neutral message texts in accordance with the application.
•
Check configurations on contacts and in operation and fault buffer, or set them according to the require-
ments.
Further Information
The following instruction should be noted:
•
As the power factor does not differentiate between capacitive and inductive, the sign of the reactive
power may be used with CFC-help as an additional criterion.
Settings
Addresses which have an appended “A” can only be changed with DIGSI, under “Additional Settings”.
The table indicates region-specific default settings. Column C (configuration) indicates the corresponding
secondary nominal current of the current transformer.
Addr. Parameter C Setting Options Default Setting Comments
0 FLEXIBLE FUNC. OFF
ON
Alarm Only
OFF Flexible Function
0 OPERRAT. MODE 3-phase
1-phase
no reference
3-phase Mode of Operation
0 MEAS. QUANTITY Please select
Current
Voltage
P forward
P reverse
Q forward
Q reverse
Power factor
Frequency
df/dt rising
df/dt falling
Binary Input
Please select Selection of Measured
Quantity
0 MEAS. METHOD Fundamental
True RMS
Positive seq.
Negative seq.
Zero sequence
Ratio I2/I1
Fundamental Selection of Measurement
Method
0 PICKUP WITH Exceeding
Dropping below
Exceeding Pickup with
0 CURRENT Ia
Ib
Ic
In
In sensitive
Ia Current
2.15.3
Functions
2.15 Flexible Protection Functions
174 SIPROTEC 4, 7SD80, Manual
E50417-G1100-C474-A2, Edition 02.2018
