Binary Output
Table E-3 Output Relay Presettings for All Devices and Ordering Variants
Binary Output Default function Function No. Description
BO1 Emer. mode 2054 Emergency mode
BO2 Alarm Sum Event 160 Alarm Summary Event
BO3 Relay PICKUP 501 Relay PICKUP
BO4 Relay TRIP 511 Relay GENERAL TRIP command
BO5 Relay TRIP 511 Relay GENERAL TRIP command
BO6 Rem.Sig 1 Rx 3573 Remote signal 1 received
BO7 PDI FO faulty 3230 PDI FO failure
PDI Cu faulty 3232 PDI Cu failure
BO8 - - -
E.3
Default Settings and Protocol-dependent Functions
E.3 Binary Output
326 SIPROTEC 4, 7SD80, Manual
E50417-G1100-C474-A2, Edition 02.2018
