Binary Input
Table E-2 Binary input presettings for all devices and ordering variants
Binary Input Default function Function No. Description
BI1 >85 DT 3pol 3504 >86 DT: >Intertrip 3 pole signal input
BI2 >87L block 32100 >87L Protection blocking signal
>87N L block 32120 >87N L Protection blocking signal
BI3 >BLOCK 50-3 7130 >BLOCK 50-3
>BLOCK 50N-3 7132 >BLOCK 50N-3
BI4 >Rem. Signal 1 3549 >Remote Signal 1 input
BI5 >52a 3p Closed 379 >52a Bkr. aux. contact (3pole closed)
>52a Bkr1 3p Cl 410 >52a Bkr1 aux. 3pClosed (for AR,CB-Test)
BI6 >52b 3p Open 380 >52b Bkr. aux. contact (3pole open)
>52b Bkr1 3p Op 411 >52b Bkr1 aux. 3p Open (for AR,CB-Test)
BI7 >Manual Close 356 >Manual close signal
E.2
Default Settings and Protocol-dependent Functions
E.2 Binary Input
SIPROTEC 4, 7SD80, Manual 325
E50417-G1100-C474-A2, Edition 02.2018
