No. Information Type of
Informa-
tion
Comments
861 Vb-nMin= MVT Vb-n Min
862 Vb-nMax= MVT Vb-n Max
863 Vc-nMin= MVT Vc-n Min
864 Vc-nMax= MVT Vc-n Max
865 Va-bMin= MVT Va-b Min
867 Va-bMax= MVT Va-b Max
868 Vb-cMin= MVT Vb-c Min
869 Vb-cMax= MVT Vb-c Max
870 Vc-aMin= MVT Vc-a Min
871 Vc-aMax= MVT Vc-a Max
874 V1 Min = MVT V1 (positive sequence) Voltage Minimum
875 V1 Max = MVT V1 (positive sequence) Voltage Maximum
880 Smin= MVT Apparent Power Minimum
881 Smax= MVT Apparent Power Maximum
882 fmin= MVT Frequency Minimum
883 fmax= MVT Frequency Maximum
1040 Pmin Forw= MVT Active Power Minimum Forward
1041 Pmax Forw= MVT Active Power Maximum Forward
1042 Pmin Rev = MVT Active Power Minimum Reverse
1043 Pmax Rev = MVT Active Power Maximum Reverse
1044 Qmin Forw= MVT Reactive Power Minimum Forward
1045 Qmax Forw= MVT Reactive Power Maximum Forward
1046 Qmin Rev = MVT Reactive Power Minimum Reverse
1047 Qmax Rev = MVT Reactive Power Maximum Reverse
1048 PFminForw= MVT Power Factor Minimum Forward
1049 PFmaxForw= MVT Power Factor Maximum Forward
1050 PFmin Rev= MVT Power Factor Minimum Reverse
1051 PFmax Rev= MVT Power Factor Maximum Reverse
10102 3V0min = MVT Min. Zero Sequence Voltage 3V0
10103 3V0max = MVT Max. Zero Sequence Voltage 3V0
Demand Measurement Setup
The long-term averages are calculated and output by the 7SD80.
Functional Description
Long-Term Averages
The long-term averages of the three phase currents Ι
x
, the positive sequence components Ι
1
for the three
phase currents, and the real power P, reactive power Q, and apparent power S are calculated within a set
period of time and indicated in primary values.
For the long-term averages mentioned above, the length of the time window for averaging and the frequency
with which it is updated can be set.
2.17.7
2.17.7.1
Functions
2.17 Auxiliary Functions
SIPROTEC 4, 7SD80, Manual 189
E50417-G1100-C474-A2, Edition 02.2018
