Addr. Parameter C Setting Options Default Setting Comments
1233 CT Err. I1 0.003 .. 1.600 A 0.050 A Current I1 for CT Angle
Error
1234 CT Err. F1 0.0 .. 5.0 ° 0.0 ° CT Angle Error at I1
1235 CT Err. I2 0.003 .. 1.600 A 1.000 A Current I2 for CT Angle
Error
1236 CT Err. F2 0.0 .. 5.0 ° 0.0 ° CT Angle Error at I2
1237 87NL:Inrush blk NO
YES
NO Inrush blocking
Information List
No. Information Type of
Informa-
tion
Comments
3190 Test 87 IntSP 87 Set test state of 87
3191 Commiss.87 IntSP 87 Set Commissioning state of 87
3192 Test 87 remote OUT 87 Remote relay in test state
3193 Comm. 87 active OUT 87 Commissioning state is active
3197 >Test 87 ON SP 87 >Set test state of 87
3198 >Test 87 OFF SP 87 >Reset test state of 87
3199 Test 87 ON/off IntSP 87 Test state of 87 ON/OFF
3200 Test 87 ONoffBI IntSP 87 Test state ON/OFF via BI
3260 >Comm. 87 ON SP 87 >Commissioning state ON
3261 >Comm. 87 OFF SP 87 >Commissioning state OFF
3262 Comm 87 ON/OFF IntSP 87 Commissioning state ON/OFF
3263 Comm 87 ONoffBI IntSP 87 Commissioning state ON/OFF via BI
32100 >87L block SP >87L Protection blocking signal
32102 87L active OUT 87L Protection is active
32103 87L Fault A OUT 87L Fault detection A
32104 87L Fault B OUT 87L Fault detection B
32105 87L Fault C OUT 87L Fault detection C
32107 87L is blocked OUT 87L Protection is blocked
32108 87L is OFF OUT 87L Protection is switched off
32109 87L allow A OUT 87L A released
32110 87L allow B OUT 87L B released
32111 87L allow C OUT 87L C released
32112 87 CTRatioAlarm OUT 87 CT primary ratio is too high
32113 87L receive blk OUT 87L receive blocking
32114 87L send blk OUT 87L send blocking
32115 87L IDYN> A OUT 87L IDYN> A
32116 87L IDYN> B OUT 87L IDYN> B
32117 87L IDYN> C OUT 87L IDYN> C
32118 87L ISTAT> A OUT 87L ISTAT> A
32119 87L ISTAT> B OUT 87L ISTAT> B
32120 >87N L block SP >87N L Protection blocking signal
32121 >87N L active OUT >87N L: Protection is active
32122 87(N)L Gen.Flt. OUT 87(N)L Fault detection
32124 >87N L I> Flt. OUT >87N L: Fault detection of I-Diff>
2.2.6.2
Functions
2.2 Phase Comparison Protection and Ground Differential Protection
64 SIPROTEC 4, 7SD80, Manual
E50417-G1100-C474-A2, Edition 02.2018
