Siemens SIPROTEC 4 7SD80 User Manual

Addr. Parameter C Setting Options Default Setting Comments
2613 67-B1 PICKUP 1A 0.10 .. 25.00 A; ∞ 2.00 A 67-B1 Pickup threshold
5A 0.50 .. 125.00 A; ∞ 10.00 A
2614 50-B1 DELAY 0.00 .. 30.00 sec; ∞ 0.30 sec 50-B1 Delay
2614 67-B1 DELAY 0.00 .. 30.00 sec; ∞ 0.30 sec 67-B1 set time delay
2615 50-B1 Inrush NO
YES
NO 50-B1 Inrush blocking
2615 67-B1 Inrush NO
YES
NO 67-B1 Inrush blocking
2616 50N-B1 PICKUP 1A 0.05 .. 25.00 A; ∞ 0.50 A 50N-B1 Pickup
5A 0.25 .. 125.00 A; ∞ 2.50 A
2616 67N-B1 PICKUP 1A 0.05 .. 25.00 A; ∞ 0.50 A 67N-B1 Pickup threshold
5A 0.25 .. 125.00 A; ∞ 2.50 A
2617 50N-B1 DELAY 0.00 .. 30.00 sec; ∞ 2.00 sec 50N-B1 Delay
2617 67N-B1 DELAY 0.00 .. 30.00 sec; ∞ 2.00 sec 67N-B1 set time delay
2618 50(N)-B1 Pil/BI NO
YES
YES Instantaneous trip via Pilot
Prot./BI
2618 67(N)-B1 Pil/BI NO
YES
NO Instantaneous trip via Pilot
Prot./BI
2620 Op.Mode50(N)-B2 ON
Only Emer. prot
OFF
Only Emer. prot Operating Mode 50(N)-B2
2620 Op.Mode67(N)-B2 ON
Only Emer. prot
OFF
Only Emer. prot Operating Mode 67(N)-B2
2621 67(N)-B2 Dir. Non-Directional
Forward
Reverse
Non-Directional 67(N)-B2 Direction
2622 67(N)-B2 on FFM Non-Directional
BLOCKED
BLOCKED 67(N)-B2 Direct. stage on
Fuse Failure
2623 50-B2 PICKUP 1A 0.10 .. 25.00 A; ∞ 1.50 A 50-B2 Pickup
5A 0.50 .. 125.00 A; ∞ 7.50 A
2623 67-B2 PICKUP 1A 0.10 .. 25.00 A; ∞ 1.50 A 67-B2 Pickup threshold
5A 0.50 .. 125.00 A; ∞ 7.50 A
2624 50-B2 DELAY 0.00 .. 30.00 sec; ∞ 0.50 sec 50-B2 Delay
2624 67-B2 DELAY 0.00 .. 30.00 sec; ∞ 0.50 sec 67-B2 set time delay
2625 50-B2 Inrush NO
YES
NO 50-B2 Inrush blocking
2625 67-B2 Inrush NO
YES
NO 67-B2 Inrush blocking
2626 50N-B2 PICKUP 1A 0.05 .. 25.00 A; ∞ 0.20 A 50N-B2 Pickup
5A 0.25 .. 125.00 A; ∞ 1.00 A
2626 67N-B2 PICKUP 1A 0.05 .. 25.00 A; ∞ 0.20 A 67N-B2 Pickup threshold
5A 0.25 .. 125.00 A; ∞ 1.00 A
2627 50N-B2 DELAY 0.00 .. 30.00 sec; ∞ 2.00 sec 50N-B2 Delay
2627 67N-B2 DELAY 0.00 .. 30.00 sec; ∞ 2.00 sec 67N-B2 set time delay
2628 50(N)-B2 Pil/BI NO
YES
NO Instantaneous trip via Pilot
Prot./BI
Functions
2.4 Backup overcurrent
86 SIPROTEC 4, 7SD80, Manual
E50417-G1100-C474-A2, Edition 02.2018
