No. Information Type of
Informa-
tion
Comments
10261 59-2-VppTimeOut OUT 59-2-Vphph TimeOut
10262 59-Vpp TRIP OUT 59-Vphph TRIP command
10263 59-1-Vpp PU AB OUT 59-1-Vphph Pickup A-B
10264 59-1-Vpp PU BC OUT 59-1-Vphph Pickup B-C
10265 59-1-Vpp PU CA OUT 59-1-Vphph Pickup C-A
10266 59-2-Vpp PU AB OUT 59-2-Vphph Pickup A-B
10267 59-2-Vpp PU BC OUT 59-2-Vphph Pickup B-C
10268 59-2-Vpp PU CA OUT 59-2-Vphph Pickup C-A
10270 59-1-3V0 Pickup OUT 59-1-3V0 Pickup
10271 59-2-3V0 Pickup OUT 59-2-3V0 Pickup
10272 59-1-3V0TimeOut OUT 59-1-3V0 TimeOut
10273 59-2-3V0TimeOut OUT 59-2-3V0 TimeOut
10274 59-3V0 TRIP OUT 59-3V0 TRIP command
10280 59-1-V1 Pickup OUT 59-1-V1 Pickup
10281 59-2-V1 Pickup OUT 59-2-V1 Pickup
10282 59-1-V1TimeOut OUT 59-1-V1 TimeOut
10283 59-2-V1TimeOut OUT 59-2-V1 TimeOut
10284 59-V1 TRIP OUT 59-V1 TRIP command
10290 59-1-V2 Pickup OUT 59-1-V2 Pickup
10291 59-2-V2 Pickup OUT 59-2-V2 Pickup
10292 59-1-V2TimeOut OUT 59-1-V2 TimeOut
10293 59-2-V2TimeOut OUT 59-2-V2 TimeOut
10294 59-V2 TRIP OUT 59-V2 TRIP command
10300 27-1-V1 Pickup OUT 27-1-V1 Pickup
10301 27-2-V1 Pickup OUT 27-2-V1 Pickup
10302 27-1-V1TimeOut OUT 27-1-V1TimeOut
10303 27-2-V1TimeOut OUT 27-2-V1TimeOut
10304 27-V1 TRIP OUT 27-V1 TRIP command
10310 27-1-Vpg Pickup OUT 27-1-Vphg Pickup
10311 27-2-Vpg Pickup OUT 27-2-Vphg Pickup
10312 27-Vpg PU A OUT 27-Vphg Pickup A
10313 27-Vpg PU B OUT 27-Vphg Pickup B
10314 27-Vpg PU C OUT 27-Vphg Pickup C
10315 27-1-VpgTimeOut OUT 27-1-Vphg TimeOut
10316 27-2-VpgTimeOut OUT 27-2-Vphg TimeOut
10317 27-Vpg TRIP OUT 27-Vphg TRIP command
10318 27-1-Vpg PU A OUT 27-1-Vphg Pickup A
10319 27-1-Vpg PU B OUT 27-1-Vphg Pickup B
10320 27-1-Vpg PU C OUT 27-1-Vphg Pickup C
10321 27-2-Vpg PU A OUT 27-2-Vphg Pickup A
10322 27-2-Vpg PU B OUT 27-2-Vphg Pickup B
10323 27-2-Vpg PU C OUT 27-2-Vphg Pickup C
10325 27-1-Vpp Pickup OUT 27-1-Vphph Pickup
10326 27-2-Vpp Pickup OUT 27-2-Vphph Pickup
10327 27-Vpp PU AB OUT 27-Vphph Pickup A-B
Functions
2.8 Undervoltage and Overvoltage Protection (optional) 27/59
SIPROTEC 4, 7SD80, Manual 121
E50417-G1100-C474-A2, Edition 02.2018
