Addr. Parameter Function C Setting Options Default Setting Comments
625A T MIN LED HOLD Device, General 0 .. 60 min; ∞ 0 min Minimum hold time of
latched LEDs
640 Start image DD Device, General image 1
image 2
image 3
image 4
image 5
image 6
image 7
image 8
image 1 Start image Default
Display
650 PDI Test Mode Device, General OFF
ON
OFF PDI Test Mode
1103 FullScaleVolt. P.System Data
2
0.4 .. 500.0 kV 10.0 kV Measurem:FullScale-
Voltage(Equipm.rating)
1104 FullScaleCurr. P.System Data
2
10 .. 20000 A 400 A Measurem:FullScaleCur-
rent(Equipm.rating)
1107 P,Q sign P.System Data
2
not reversed
reversed
not reversed P,Q operational measured
values sign
1130A PoleOpenCurrent P.System Data
2
1A 0.05 .. 1.00 A 0.10 A Pole Open Current
Threshold
5A 0.25 .. 5.00 A 0.50 A
1131A PoleOpenVoltage P.System Data
2
2 .. 70 V 30 V Pole Open Voltage
Threshold
1132A SI Time all Cl. P.System Data
2
0.01 .. 30.00 sec 0.10 sec Seal-in Time after ALL
closures
1133A T DELAY SOTF P.System Data
2
0.05 .. 30.00 sec 0.25 sec minimal time for line
open before SOTF
1134 Line Closure P.System Data
2
only with ManCl
I OR V or ManCl
52a OR I or M/C
I or Man.Close
only with ManCl Recognition of Line
Closures with
1135 Reset Trip CMD P.System Data
2
CurrentOpenPole
Current AND 52a
Pickup Reset
CurrentOpenPole RESET of Trip Command
1150A SI Time Man.Cl P.System Data
2
0.01 .. 30.00 sec 0.30 sec Seal-in Time after
MANUAL closures
1152 Man.Clos. Imp. P.System Data
2
(Einstellmöglich-
keiten anwendung-
sabhängig)
none MANUAL Closure Impulse
after CONTROL
1201 87L PCC-Prot. 87 Diff. Prot. OFF
ON
ON Phase current comparison
protection
1202 87L Idyn> 87 Diff. Prot. 1A 0.20 .. 20.00 A; ∞ 0.33 A Dynamic trip threshold
5A 1.00 .. 100.00 A; ∞ 1.65 A
1203 87L Idyn close> 87 Diff. Prot. 1A 0.20 .. 20.00 A; ∞ 0.33 A Dynamic trip threshold
line closure
5A 1.00 .. 100.00 A; ∞ 1.65 A
1204 87L Isteady> 87 Diff. Prot. 1A 0.50 .. 20.00 A; ∞ 1.33 A Steady pick up threshold
5A 2.50 .. 100.00 A; ∞ 6.65 A
1205 87L I min 87 Diff. Prot. 1A 0.10 .. 20.00 A; ∞ 1.00 A Minimal phase current
5A 0.50 .. 100.00 A; ∞ 5.00 A
1206 87L Trip Delay 87 Diff. Prot. 0.00 .. 0.10 sec 0.00 sec Trip Delay
Functions, Settings, Information
F.2 Settings
SIPROTEC 4, 7SD80, Manual 339
E50417-G1100-C474-A2, Edition 02.2018
