Siemens SIPROTEC 4 7SD80

Addr. Parameter Function C Setting Options Default Setting Comments
2202 Trip Time DELAY DTT Direct Trip 0.00 .. 30.00 sec; ∞ 0.00 sec Trip Time Delay
2203 Iph rel.Trip DTT Direct Trip 1A 0.0 .. 25.0 A; ∞ 0.0 A Minimal Phase Current to
release trip
5A 0.0 .. 125.0 A; ∞ 0.0 A
2204 3I0 rel.Trip DTT Direct Trip 1A 0.0 .. 25.0 A; ∞ 0.0 A Minimal 3I0 Current to
release trip
5A 0.0 .. 125.0 A; ∞ 0.0 A
2301 INRUSH REST. InRushRestraint OFF
ON
OFF Inrush Restraint
2302 2nd HARMONIC InRushRestraint 10 .. 45 % 15 % 2nd. harmonic in % of
fundamental
2303 CROSS BLOCK InRushRestraint NO
YES
NO Cross Block
2305 MAX INRUSH PEAK InRushRestraint 1A 1.1 .. 25.0 A 15.0 A Maximum inrush-peak
value
5A 5.5 .. 125.0 A 75.0 A
2310 CROSSB 2HM InRushRestraint 0.00 .. 60.00 sec; ∞ 0.00 sec Time for Crossblock with
2nd harmonic
2603A 67N dir. meas. Back-Up O/C V0/I0 or V2/I2
with V0/I0
with V2/I2
V0/I0 or V2/I2 67N, Measurement of
direction
2610 Op.Mode50(N)-B1 Back-Up O/C ON
Only Emer. prot
OFF
OFF Operating Mode 50(N)-B1
2610 Op.Mode67(N)-B1 Back-Up O/C ON
Only Emer. prot
OFF
OFF Operating Mode 67(N)-B1
2611 67(N)-B1 Dir. Back-Up O/C Non-Directional
Forward
Reverse
Non-Directional 67(N)-B1 Direction
2612 67(N)-B1 on FFM Back-Up O/C Non-Directional
BLOCKED
BLOCKED 67(N)-B1 Direct. stage on
Fuse Failure
2613 50-B1 PICKUP Back-Up O/C 1A 0.10 .. 25.00 A; ∞ 2.00 A 50-B1 Pickup
5A 0.50 .. 125.00 A; ∞ 10.00 A
2613 67-B1 PICKUP Back-Up O/C 1A 0.10 .. 25.00 A; ∞ 2.00 A 67-B1 Pickup threshold
5A 0.50 .. 125.00 A; ∞ 10.00 A
2614 50-B1 DELAY Back-Up O/C 0.00 .. 30.00 sec; ∞ 0.30 sec 50-B1 Delay
2614 67-B1 DELAY Back-Up O/C 0.00 .. 30.00 sec; ∞ 0.30 sec 67-B1 set time delay
2615 50-B1 Inrush Back-Up O/C NO
YES
NO 50-B1 Inrush blocking
2615 67-B1 Inrush Back-Up O/C NO
YES
NO 67-B1 Inrush blocking
2616 50N-B1 PICKUP Back-Up O/C 1A 0.05 .. 25.00 A; ∞ 0.50 A 50N-B1 Pickup
5A 0.25 .. 125.00 A; ∞ 2.50 A
2616 67N-B1 PICKUP Back-Up O/C 1A 0.05 .. 25.00 A; ∞ 0.50 A 67N-B1 Pickup threshold
5A 0.25 .. 125.00 A; ∞ 2.50 A
2617 50N-B1 DELAY Back-Up O/C 0.00 .. 30.00 sec; ∞ 2.00 sec 50N-B1 Delay
2617 67N-B1 DELAY Back-Up O/C 0.00 .. 30.00 sec; ∞ 2.00 sec 67N-B1 set time delay
2618 50(N)-B1 Pil/BI Back-Up O/C NO
YES
YES Instantaneous trip via
Pilot Prot./BI
Functions, Settings, Information
F.2 Settings
SIPROTEC 4, 7SD80, Manual 341
E50417-G1100-C474-A2, Edition 02.2018
