No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
2889 79 1st cycle zone exten-
sion release (79 1.CycZo-
neRel)
79 Auto
Recl.
OUT * * * LED BO 40 16
0
1 Yes
2890 79 2nd cycle zone exten-
sion release (79 2.CycZo-
neRel)
79 Auto
Recl.
OUT * * * LED BO 40 16
9
1 Yes
2894 79 Remote close signal
send (79 Remote Close)
79 Auto
Recl.
OUT * ON * LED BO 40 12
9
2 Yes
2896 No. of 1st AR-cycle CLOSE
commands,3pole (79
#Close1./3p=)
Statistics VI
2898 No. of higher AR-cycle
CLOSE commands,3p (79
#Close2./3p=)
Statistics VI
3102 Tolerance invalid in phase
A (2nd Harmonic A)
InRushRes-
traint
OUT * * LED BO 92 89 1 Yes
3103 Tolerance invalid in phase
B (2nd Harmonic B)
InRushRes-
traint
OUT * * LED BO 92 90 1 Yes
3104 Tolerance invalid in phase
C (2nd Harmonic C)
InRushRes-
traint
OUT * * LED BO 92 91 1 Yes
3190 87 Set test state of 87
(Test 87)
87 Diff.
Prot.
IntS
P
On
Of
f
* * LED FK
TO
NL
IN
E
BO 92 10
6
1 Yes
3191 87 Set Commissioning
state of 87 (Commiss.87)
87 Diff.
Prot.
IntS
P
O
N
OF
F
* * LED FK
TO
NL
IN
E
BO 92 10
7
1 Yes
3192 87 Remote relay in test
state (Test 87 remote)
87 Diff.
Prot.
OUT On
Of
f
* * LED BO 92 10
8
1 Yes
3193 87 Commissioning state
is active (Comm. 87
active)
87 Diff.
Prot.
OUT On
Of
f
* * LED BO 92 10
9
1 Yes
3197 87 >Set test state of 87
(>Test 87 ON)
87 Diff.
Prot.
SP O
N
OF
F
* * LED BI BO
3198 87 >Reset test state of 87
(>Test 87 OFF)
87 Diff.
Prot.
SP O
N
OF
F
* * LED BI BO
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7SD80, Manual 371
E50417-G1100-C474-A2, Edition 02.2018
