Siemens SIPROTEC 4 7SD80 User Manual

No. Information Type of
Informa-
tion
Comments
7107 >BLOCK 50N-B1 SP >BLOCK 50N-B1 Backup OverCurrent
7108 >BLOCK 50N-B2 SP >BLOCK 50N-B2 Backup OverCurrent
7109 >BLOCK 51N SP >BLOCK 51N Backup OverCurrent
7110 >5X-B InstTRIP SP >50(N)/51(N) BackupO/C InstantaneousTrip
7112 >BLOCK 67-TOC SP >BLOCK Backup OverCurrent 67-TOC
7114 >BLOCK 67N-TOC SP >BLOCK Backup OverCurrent 67N-TOC
7115 >BLOCK 67-B1 SP >BLOCK Backup OverCurrent 67-B1
7116 >BLOCK 67N-B1 SP >BLOCK Backup OverCurrent 67N-B1
7117 >BLOCK 67-B2 SP >BLOCK Backup OverCurrent 67-B2
7118 >BLOCK 67N-B2 SP >BLOCK Backup OverCurrent 67N-B2
7130 >BLOCK 50-3 SP >BLOCK 50-3
7132 >BLOCK 50N-3 SP >BLOCK 50N-3
7152 5X-B BLOCK OUT 50(N)/51(N) Backup O/C is BLOCKED
7153 5X-B ACTIVE OUT 50(N)/51(N) Backup O/C is ACTIVE
7154 50(N)-B2 OFF OUT Backup O/C stage 50(N)-B2 is sw. OFF
7155 50(N)-B1 OFF OUT Backup O/C stage 50(N)-B1 is sw. OFF
7156 50(N)-3 OFF OUT Backup O/C stage 50(N)-3 is sw. OFF
7157 51(N)-B OFF OUT Backup O/C stage 51(N)-B is sw. OFF
7161 5X-B PICKUP OUT 50(N)/51(N) Backup O/C PICKED UP
7162 5X-B Pickup ØA OUT 50(N)/51(N) Backup O/C PICKUP Phase A
7163 5X-B Pickup ØB OUT 50(N)/51(N) Backup O/C PICKUP Phase B
7164 5X-B Pickup ØC OUT 50(N)/51(N) Backup O/C PICKUP Phase C
7165 5X-B Pickup Gnd OUT 50(N)/51(N) Backup O/C PICKUP GROUND
7191 50(N)-B1 PICKUP OUT 50(N)-B1 Pickup
7192 50(N)-B2 PICKUP OUT 50(N)-B2 Pickup
7193 51(N)-B PICKUP OUT 51(N)-B Pickup
7201 50-3 PICKUP OUT 50-3 Pickup
7211 5X-B TRIP OUT 50(N)/51(N)-B General TRIP command
7221 50(N)-B1 TRIP OUT 50(N)-B1 TRIP
7222 50(N)-B2 TRIP OUT 50(N)-B2 TRIP
7223 51(N)-B TRIP OUT 51(N)-B TRIP
7235 50-3 TRIP OUT 50-3 TRIP
7250 67(N)-B1 PICKUP OUT 67(N)-B1 Pickup
7251 67(N)-B2 PICKUP OUT 67(N)-B2 Pickup
7252 67(N)-TOC PICK. OUT 67(N)-TOC Pickup
7253 67(N) TRIP OUT 67(N) General TRIP command
7254 67(N)-B1 TRIP OUT 67(N)-B1 TRIP
7255 67(N)-B2 TRIP OUT 67(N)-B2 TRIP
7256 67(N)-TOC TRIP OUT 67(N)-TOC TRIP
7257 67 forward ØA OUT 67 Phase A forward
7258 67 forward ØB OUT 67 Phase B forward
7259 67 forward ØC OUT 67 Phase C forward
7260 67N forward GND OUT 67N Gnd forward
7261 67 reverse ØA OUT 67 Phase A reverse
7262 67 reverse ØB OUT 67 Phase B reverse
Functions
2.4 Backup overcurrent
SIPROTEC 4, 7SD80, Manual 89
E50417-G1100-C474-A2, Edition 02.2018
