Siemens SIPROTEC 5 V8.30 User Manual

•
Ethernet Modules
Application: Ethernet-based communication to the substation automation technology via substation-
control protocols (for example, IEC 61850 and DNP3)
– Secure communication to DIGSI 5
– Communication between the devices (IEC 61850-GOOSE)
– Synchrophasor protocol (IEEE C37.118 - PMU)
The modules can be operated with or without an integrated switch.
•
Long-distance modules
Application: Direct protection interface communication over long distances using multimode or single-
mode optical fibers.
The designation of the modules corresponds to the following scheme, which is typically explained with the
module USART-AB-1EL. The module designation consists of 3 blocks.
1st block Type of module
USART = Serial module for short or long distance
ETH = Ethernet module
2nd block Unique code for the module in the product code of the device
The code consists of 2 letters.
3rd block Number and physical design of the connections
1 = 1 connection (1 channel)
2 = 2 connections (2 channels)
EL = Electrical connection
FO = Fiber-optic connection
LDFO = Long-distance transmission via optical fibers
Communication Applications of the Plug-In Modules
You can find information on communication applications for the plug-in modules in the following tables.
Plug-In Modules for the Communication
Table 4-1
Plug-In Modules for Applications with the Protection Interface and for Other Applications
Plug-In Module
USART-AB-1EL USART-AC-2EL USART-AD-1FO USART-AE-2FO
ETH-BA-2EL
ETH-BB-2FO ETH-BD-2FO
1
USART-AF-1LDFO USART-AW-2LDFO USART-AG-1LDFO
USART-AU-2LDFO
USART-AK-1LDFO USART-AV-2LDFO USART-AH-1LDFO
2
USART-AJ-1LDFO
3
USART-AX-2LDFO
4
USART-AY-2LDFO
5
ANAI-CA-4EL ARC-CD-3FO
Physical Connection
1 x electrical serial RS485, RJ45 ■
2 x electrical serial RS485, RJ45 ■
4.2.2
1
For modular devices only (not for 7ST85 and 6MD89)
2
USART-AH-1LDFO only in connection with USART-AJ-1LDFO or USART-AY-2LDFO
3
USART-AJ-1LDFO only in connection with USART-AH-1LDFO or USART-AX-2LDFO
4
USART-AX-2LDFO only in connection with USART-AJ-1LDFO or USART-AY-2LDFO
5
USART-AY-2LDFO only in connection with USART-AH-1LDFO or USART-AX-2LDFO
Plug-In Modules
4.2 Communication Modules
156 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-J, Edition 08.2020
