Expanding Modular Devices
Flush-Mounting Devices
Basic Rules for Expansion
NOTE
Prepare the following tools for the device expansion:
•
Phillips screwdriver size PZ1 and PZ2
•
Screwdriver DIN 4 x 0.8
•
During assembly, use the prescribed torques (see chapter 6.13 Design Data).
Comply with the following basic rules when expanding devices:
²
Always fit the base module on the left in the 1st device row.
²
Always fit the expansion modules from left to right.
²
Always fit the expansion module with the key switches as the 1st module next to the base module.
²
Always fit the expansion modules without LEDs last.
²
Always install a power-supply module PS203 on the left as the first unit in the 2nd device row.
²
Note that the PS203 must always have the same rated voltage as the base module.
²
In the 2nd device row, mount only input and output modules without LEDs.
²
Always mount the redundant power-supply module PS204 at the very right in the corresponding row
(seen from the front). If a CB202 PCB assembly is used in the row, this CB202 PCB assembly must always
be plugged on the right of the power-supply module PS204 (at the very right). You can find an example
for this in chapter 3.1.4.2 Positioning Specifications.
²
Note that the power-supply module PS204 must always have the same rated voltage as the base module.
5.2
5.2.1
5.2.1.1
Working on the Device
5.2 Expanding Modular Devices
182 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-J, Edition 08.2020
