Battery
Type CR2032
Button cell
Lithium
Voltage 3 V
Capacity 230 mAh
Average service life of the battery, unpowered after removal of protec-
tive film
At least 6 months
Service life of the battery in the activated state with protective film
removed
10 years
Use button cells from manufacturers like Varta, Panasonic, or Duracell.
NOTE
After the Battery fault indication, you must replace the battery within 2 weeks. If ignored, data loss may
occur.
6.19
Technical Data
6.19 Battery
SIPROTEC 5, Hardware Description, Manual 273
C53000-G5040-C002-J, Edition 08.2020
