Plug-In Module
USART-AB-1EL USART-AC-2EL USART-AD-1FO USART-AE-2FO
ETH-BA-2EL
ETH-BB-2FO ETH-BD-2FO
1
USART-AF-1LDFO USART-AW-2LDFO USART-AG-1LDFO
USART-AU-2LDFO
USART-AK-1LDFO USART-AV-2LDFO USART-AH-1LDFO
2
USART-AJ-1LDFO
3
USART-AX-2LDFO
4
USART-AY-2LDFO
5
ANAI-CA-4EL ARC-CD-3FO
SUP Ethernet (Slave Unit Protocol) for
connecting external temperature or 20-
mA measuring devices
■ ■
Diagnosis: Ethernet module homepage
(http)
■ ■ ■
Measuring transducer, 4 inputs, DC
±20 mA
■
Arc protection ■
Additional Ethernet protocols and services
DHCP, DCP (automatic IP configuration) ■ ■ ■
Line Mode ■ ■ ■
PRP (Ethernet ring redundancy) ■ ■ ■
HSR (Ethernet ring redundancy)
8
■ ■ ■
RSTP (Ethernet ring redundancy) ■ ■ ■
SNTP (time synchronization via Ethernet) ■ ■ ■
SNMP V3 (network management
protocol)
■ ■ ■
9
IEEE 1588v2 (PTP protocol via Ethernet –
ms accuracy)
■ ■
IEEE 1588v2 (PTP protocol via Ethernet –
µs accuracy)
10
■
IEEE 802.1q (VLAN) ■
i
i
NOTE
The USART and ETH plug-in module types can be used in slots E and F in the base module as well as in slots
N and P in the CB202 expansion module. They are not intended for use in slot M in the CB202 expansion
module.
The plug-in modules of types ANAI and ARC can be used in both slots in the base module (ports E and F), as
well as in all slots in the expansion module CB202 (ports M, N, and P).
Serial Modules for Short Distances
Special Features of Serial Electrical Modules
The serial electrical modules are equipped with RJ45 connections. These are not Ethernet connections. The
serial signals of the RS485 interface are routed to the RJ45 connections (see following figure).
4.2.3
4.2.3.1
1
For modular devices only (not for 7ST85 and 6MD89)
2
USART-AH-1LDFO only in connection with USART-AJ-1LDFO or USART-AY-2LDFO
3
USART-AJ-1LDFO only in connection with USART-AH-1LDFO or USART-AX-2LDFO
4
USART-AX-2LDFO only in connection with USART-AJ-1LDFO or USART-AY-2LDFO
5
USART-AY-2LDFO only in connection with USART-AH-1LDFO or USART-AX-2LDFO
8
HSR is available in the ETH-BD-2FO module for V8.30 and higher, without supporting the IEEE 1588v2 transparent clock.
9
Available for V8.30 and higher
10
SFP accuracy is 1 ms with optional RJ45
Plug-In Modules
4.2 Communication Modules
SIPROTEC 5, Hardware Description, Manual 159
C53000-G5040-C002-J, Edition 08.2020
