Surface-Mounted Devices with Detached On-Site Operation Panel
Description
NOTE
The basic device structure is described in chapter 2.1.1 Description .
The surface-mounted devices with detached on-site operation panel are a variant of the surface-mounted
devices with an integrated on-site operation panel. The essential difference is that you can fit the on-site oper-
ation panel separately from the device. The distance frames are not assembled in this device type.
Base Module
The distance between the installation location of the device and that of the on-site operation panel is limited
to not more than 5 m (196.85 in) by the length of the connecting cable. The on-site operation panel must be
grounded. You can find information about grounding in chapter Grounding an On-Site Operation Panel,
Page 181.
NOTE
Cables with a length of 5 m (196.85 in) are only specified for PCs and laptop computers with a USB2
connection. These cables are not specified for PCs and laptop computers with a USB3 connection.
Cables with a length of 2.5 m (98.43 in) are specified for USB2 and USB3 connections.
2.3
2.3.1
Forms of Devices and On-Site Operation Panels
2.3 Surface-Mounted Devices with Detached On-Site Operation Panel
SIPROTEC 5, Hardware Description, Manual 37
C53000-G5040-C002-J, Edition 08.2020
