Module Designation Function Description
IO233
•
Input module with special version for binary inputs. You can find more infor-
mation in chapter 6 Technical Data.
•
48 binary inputs
IO240
•
Input module
•
4 current measuring inputs (GIS LPIT Rogowski coil or LPCT)
•
4 voltage measuring inputs (GIS LPIT volt. or LPVT)
•
4 temperature inputs (PT100)
Input and Output Module IO201
Description
The terminals for the following are located on the input and output module IO201:
•
4 current transformers (optionally protection-class current transformers or instrument transformers)
•
8 binary inputs
•
6 binary outputs, of which:
– 4 high-speed make contacts (type F)
– 2 high-speed change-over contacts (type F)
The connections are distributed over:
•
1 x 8-pole current terminal
•
3 x 14-pole voltage terminal
3.2.2
3.2.2.1
Electronic Modules
3.2 Input and Output Modules of the Modular Devices
SIPROTEC 5, Hardware Description, Manual 65
C53000-G5040-C002-J, Edition 08.2020
