Environmental Conditions
Temperatures
Type test, in operation
(in compliance with IEC 60068-2-1 and
IEC 60068-2-2, test Ad for 16 h and test Bd for 16 h)
-25 °C to +85 °C
Temporarily permissible during operation (tested for
96 h)
-25 °C to +70 °C
Load conditions for the non-modular devices: With
temperatures above 55 °C, no more than 50 % of the
binary inputs and relay outputs per printed circuit
board assembly are allowed to be continuously active.
Readability of the display may be impaired below
-10 °C and above +55 °C.
Recommended for uninterrupted duty
(in compliance with IEC 60255-1)
-10 °C to +55 °C
Temperatures for continuous storage -25 °C to +55 °C
Type test, transport and storage for 16 h -40 °C to +85 °C
Heat-related limitations for the binary inputs on the IO216 input module (modular devices)
Switching thresholds Up to 55 °C Up to 70 °C
220 V operating voltage All 16 binary inputs usable for uninter-
rupted duty
10 binary inputs usable for uninter-
rupted duty
Heat-related limitations for the binary inputs on the IO230 input module (modular devices)
Switching thresholds Up to 40 °C Up to 55 °C Up to 70 °C
Range 1 for 24 V, 48 V,
and 60 V operating
voltage
All 48 binary inputs usable
for uninterrupted duty
All 48 binary inputs usable
for uninterrupted duty
All 48 binary inputs usable
for uninterrupted duty
Range 2 for 110 V and
125 V operating voltage
All 48 binary inputs usable
for uninterrupted duty
All 48 binary inputs usable
for uninterrupted duty
36 binary inputs usable
for uninterrupted duty
(max. 3 in each group of 4
at the same time)
Range 3 for 220 V and
250 V operating voltage
36 binary inputs usable
for uninterrupted duty
(max. 3 in each group of 4
at the same time)
24 binary inputs usable
for uninterrupted duty
(max. 2 in each group of 4
at the same time)
12 binary inputs usable
for uninterrupted duty
(max. 1 in each group of 4
at the same time)
NOTE
At an ambient temperature of 55 °C to 70 °C, a maximum of 36 relays per row can be switched on simulta-
neously.
Heat-related limitations for the binary inputs on the IO231 input module (modular devices)
Switching thresholds Up to 40 °C Up to 55 °C Up to 70 °C
Range 1 for 24 V, 48 V,
and 60 V operating
voltage
All 24 binary inputs usable
for uninterrupted duty
All 24 binary inputs usable
for uninterrupted duty
All 24 binary inputs usable
for uninterrupted duty
6.9
Technical Data
6.9 Environmental Conditions
SIPROTEC 5, Hardware Description, Manual 239
C53000-G5040-C002-J, Edition 08.2020
