Siemens SIPROTEC 5 Hardware Description

Plug-In Module
Module Type: USART-AB-1EL
Module Type: USART-AC-2EL
Module Type: USART-AD-1FO
Module Type: USART-AE-2FO
Module Type: ETH-BA-2EL
Module Type: ETH-BB-2FO
Module Type: USART-AF-1LDFO
Module Type: USART-AW-2LDFO
Module Type: USART-AG-1LDFO
Module Type: USART-AU-2LDFO
Module Type: USART-AK-1LDFO
Module Type: USART-AV-2LDFO
Module Type: USART-AH-1LDFO
Module Type: USART-AJ-1LDFO
Module Type: USART-AX-2LDFO
Module Type: USART-AY-2LDFO
2 x optical serial, 820 nm, ST connector,
2 km via 62.5/125 μm multimode optical
fiber
●
2 x electrical Ethernet 100 Mbit/s, RJ45,
20 m
●
2 x optical Ethernet 100 Mbit/s,
1300 nm, duplex LC plug, 2 km via
50/125 μm or 62.5/125 μm multimode
optical fiber
●
1 x optical serial, 1300 nm, duplex LC
plug, 24 km via 9/125 μm singlemode
optical fiber or 4 km via 62.5/125 μm
multimode optical fiber
●
2 x optical serial, 1300 nm, duplex LC
plug, 24 km via 9/125 μm singlemode
optical fiber or 4 km via 62.5/125 μm
multimode optical fiber
●
1 x optical serial, 1300 nm, duplex LC
plug, 60 km via 9/125 μm singlemode
optical fiber
●
2 x optical serial, 1300 nm, duplex LC
plug, 60 km via 9/125 μm singlemode
optical fiber
●
1 x optical serial, 1550 nm, duplex LC
plug, 100 km via 9/125 μm singlemode
optical fiber
●
2 x optical serial, 1550 nm, duplex LC
plug, 100 km via 9/125 μm singlemode
optical fiber
●
1 x optical serial, bidirectional via
1 common optical fiber, 1300 nm/
1550 nm (Tx/Rx), 2 x simplex LC plugs,
40 km via 9/125 μm singlemode optical
fiber
●
1 x optical serial, bidirectional via
1 common optical fiber, 1550 nm/
1300 nm (Tx/Rx), simplex LC plug, 40 km
via 9/125 μm singlemode optical fiber
●
2 x optical serial, bidirectional via
1 common optical fiber, 1300 nm/
1550 nm (Tx/Rx), 2 x simplex LC plugs,
40 km via 9/125 μm singlemode optical
fiber
●
Plug-In Modules
4.2 Communication Modules
SIPROTEC 5, Hardware Description, Manual 133
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
