Siemens SIPROTEC 5 Hardware Description

Plug-In Module
Module Type: USART-AB-1EL
Module Type: USART-AC-2EL
Module Type: USART-AD-1FO
Module Type: USART-AE-2FO
Module Type: ETH-BA-2EL
Module Type: ETH-BB-2FO
Module Type: USART-AF-1LDFO
Module Type: USART-AW-2LDFO
Module Type: USART-AG-1LDFO
Module Type: USART-AU-2LDFO
Module Type: USART-AK-1LDFO
Module Type: USART-AV-2LDFO
Module Type: USART-AH-1LDFO
Module Type: USART-AJ-1LDFO
Module Type: USART-AX-2LDFO
Module Type: USART-AY-2LDFO
2 x optical serial, bidirectional via
1 common optical fiber, 1550 nm/
1300 nm (Tx/Rx), 2 x simplex LC plugs,
40 km via 9/125 μm singlemode optical
fiber
●
Applications
DIGSI 5 Protocol ● ●
IRIG-B, DCF77, high-precision 1-s pulse
IEC 61850-8-1 server
You can find more information in the
Communication Protocols Manual,
chapter IEC 61850.
● ●
IEC 60870-5-103 ● ● ● ●
IEC 60870-5-104 ● ●
Modbus TCP ● ●
DNP3 serial ● ● ● ●
DNP3 via Ethernet ● ●
Synchrophasor (IEEE C37.118 – IP) ● ●
Protection interface (Sync. HDLC) ● ● ● ● ● ● ● ● ● ● ● ●
Protection interface (IEEE C37.94) ● ●
PROFINET IO ● ●
SUP Serial (Slave Unit Protocol) for
connecting external temperature or
20‑mA measuring devices
● ● ● ●
SUP Ethernet (Slave Unit Protocol) for
connecting external temperature or
20‑mA measuring devices
● ●
Additional Ethernet Protocols and
Services
DHCP (automatic IP configuration), DCP ● ●
RSTP (Ethernet ring redundancy) ● ●
PRP (Parallel Redundancy Protocol) ● ●
HSR (High-availability uninterruptible
ring redundancy)
● ●
SNTP (time synchronization via Ethernet) ● ●
IEEE 1588v2 (PTP protocol via Ethernet) ● ●
SNMP V3 (network management
protocol)
● ●
Diagnosis: Ethernet module homepage
(http)
● ●
Plug-In Modules
4.2 Communication Modules
134 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
