2.9 Backup Time Overcurrent Protection
121
7SD610 Manual
C53000-G1176-C145-4
7177 O/C Pickup L12E OUT Backup O/C Pickup L12E
7178 O/C PU 1p. L3 OUT Backup O/C Pickup - Only L3
7179 O/C Pickup L3E OUT Backup O/C Pickup L3E
7180 O/C Pickup L31 OUT Backup O/C Pickup L31
7181 O/C Pickup L31E OUT Backup O/C Pickup L31E
7182 O/C Pickup L23 OUT Backup O/C Pickup L23
7183 O/C Pickup L23E OUT Backup O/C Pickup L23E
7184 O/C Pickup L123 OUT Backup O/C Pickup L123
7185 O/C PickupL123E OUT Backup O/C Pickup L123E
7191 O/C PICKUP I>> OUT Backup O/C Pickup I>>
7192 O/C PICKUP I> OUT Backup O/C Pickup I>
7193 O/C PICKUP Ip OUT Backup O/C Pickup Ip
7201 I-STUB PICKUP OUT O/C I-STUB Pickup
7202 O/C PICK. I>Dir OUT Backup O/C Pickup I> directional
7203 O/C PICK. IpDir OUT Backup O/C Pickup Ip directional
7211 O/C TRIP OUT Backup O/C General TRIP command
7212 O/C TRIP 1p.L1 OUT Backup O/C TRIP - Only L1
7213 O/C TRIP 1p.L2 OUT Backup O/C TRIP - Only L2
7214 O/C TRIP 1p.L3 OUT Backup O/C TRIP - Only L3
7215 O/C TRIP L123 OUT Backup O/C TRIP Phases L123
7221 O/C TRIP I>> OUT Backup O/C TRIP I>>
7222 O/C TRIP I> OUT Backup O/C TRIP I>
7223 O/C TRIP Ip OUT Backup O/C TRIP Ip
7235 I-STUB TRIP OUT O/C I-STUB TRIP
7236 O/C TRIP I>Dir. OUT Backup O/C TRIP I> directional
7237 O/C TRIP IpDir. OUT Backup O/C Pickup Ip directional
7240 O/C L1 forward OUT Backup O/C L1 forward direction
7241 O/C L2 forward OUT Backup O/C L2 forward direction
7242 O/C L3 forward OUT Backup O/C L3 forward direction
7243 O/C 3I0 forward OUT Backup O/C 3I0 forward direction
7244 O/C L1 reverse OUT Backup O/C L1 reverse direction
7245 O/C L2 reverse OUT Backup O/C L2 reverse direction
7246 O/C L3 reverse OUT Backup O/C L3 reverse direction
7247 O/C 3I0 reverse OUT Backup O/C 3I0 reverse direction
7248 O/C Dir.forward OUT Backup O/C forward direction
7249 O/C Dir.reverse OUT Backup O/C reverse direction
No. Information Type of In-
formation
Comments
