Siemens SIPROTEC 7SD610 User Manual

2.17 Additional Functions
255
7SD610 Manual
C53000-G1176-C145-4
Table 2-15 Operational metered values
2.17.9.2 Setting Notes
Retrieving
parameters
The SIPROTEC® System Description describes in detail how to read out the statistical
counters via the device front panel or DIGSI. The values are added up in direction of
the protected object, provided the direction was set as „forward“ (address 201).
2.17.9.3 Information List
Measured values Primary
W
p
+ Active power, output kWh, MWh, GWh
W
p
– Active power, input kWh, MWh, GWh
W
q
+ Reactive power, output kVARh, MVARh, GVARh
W
q
– Reactive power, input kVARh, MVARh, GVARh
No. Information Type of In-
formation
Comments
- Meter res IntSP_Ev Reset meter
888 Wp(puls) PMV Pulsed Energy Wp (active)
889 Wq(puls) PMV Pulsed Energy Wq (reactive)
916 Wp∆= - Increment of active energy
917 Wq∆= - Increment of reactive energy
924 Wp+= MVMV Wp Forward
925 Wq+= MVMV Wq Forward
928 Wp-= MVMV Wp Reverse
929 Wq-= MVMV Wq Reverse
