2.17 Additional Functions
247
7SD610 Manual
C53000-G1176-C145-4
Interrupted
currents
Furthermore, for each trip command the interrupted current for each pole is acquired,
output in the trip log and accumulated in a memory. The maximum interrupted current
is stored as well. The indicated measured values are indicated in primary values.
Transmission
Statistics
In 7SD610 the protection communication is registered in statistics. The transmission
times of the information between the devices via interfaces (send and receive) are
measured continuously. The values are kept stored in the statistics folder. The avail-
ability of the transmission media is also reported. The availability is indicated in % min
and % h. This enables an evaluation of the transmission quality.
If GPS synchronization is configured, the transmission times for each direction and
each protection data interface are regularly measured and indicated as long as GPS
synchronization is intact.
2.17.3.2 Information List
2.17.4 Measurement During Operation
2.17.4.1 Function Description
A series of measured values and the values derived from them are available for on-
site retrieval or for data transfer.
A precondition for the correct display of primary and percentage values is the complete
and correct entry of the nominal values of the instrument transformers and the power
system as well as the transformation ratio of the current and voltage transformers in
the earth paths.
No. Information Type of In-
formation
Comments
1000 # TRIPs= VI Number of breaker TRIP commands
1001 TripNo L1= VI Number of breaker TRIP commands L1
1002 TripNo L2= VI Number of breaker TRIP commands L2
1003 TripNo L3= VI Number of breaker TRIP commands L3
1027 Σ IL1 = VI Accumulation of interrupted current L1
1028 Σ IL2 = VI Accumulation of interrupted current L2
1029 Σ IL3 = VI Accumulation of interrupted current L3
1030 Max IL1 = VI Max. fault current Phase L1
1031 Max IL2 = VI Max. fault current Phase L2
1032 Max IL3 = VI Max. fault current Phase L3
2895 AR #Close1./1p= VI No. of 1st AR-cycle CLOSE commands,1pole
2896 AR #Close1./3p= VI No. of 1st AR-cycle CLOSE commands,3pole
2897 AR #Close2./1p= VI No. of higher AR-cycle CLOSE commands,1p
2898 AR #Close2./3p= VI No. of higher AR-cycle CLOSE commands,3p
7751 PI1 TD MV Prot.Interface 1:Transmission delay
7753 PI1A/m MV Prot.Interface 1: Availability per min.
7754 PI1A/h MV Prot.Interface 1: Availability per hour
7875 PI1 TD R MV Prot.Interface 1:Transmission delay rec.
7876 PI1 TD S MV Prot.Interface 1:Transmission delay send
