2.16 Function Control and Circuit Breaker Test
237
7SD610 Manual
C53000-G1176-C145-4
2.16.3.4 Setting Notes
Fault Messages Pickup of a new protective function generally turns off any previously lit LEDs, so that
only the latest fault is displayed at any time. It can be selected whether the stored LED
displays and the spontaneous indications on the display appear upon renewed pickup,
or only after a renewed trip signal is issued. In order to enter the desired type of dis-
play, select the submenu Device in the SETTINGS menu. At address 610
FltDisp.LED/LCD the two alternatives Target on PU and Target on TRIP („No
trip - no flag“) are offered.
After startup of a device featuring a 4-line display, measured values are displayed by
default. Use the arrow keys on the device front to select the different represenations
of the measured values for the so-called default display. The start page of the default
display, which is displayed by default after startup of the device, can be selected via
parameter 640 Start image DD. The available representation types for the mea-
sured values are listed in the appendix .
2.16.3.5 Settings
2.16.3.6 Information List
Addr. Parameter Setting Options Default Setting Comments
610 FltDisp.LED/LCD Target on PU
Target on TRIP
Target on PU Fault Display on LED / LCD
640 Start image DD image 1
image 2
image 3
image 4
image 5
image 6
image 1 Start image Default Display
No. Information Type of In-
formation
Comments
- Test mode IntSP Test mode
- DataStop IntSP Stop data transmission
- UnlockDT IntSP Unlock data transmission via BI
- Reset LED IntSP Reset LED
- SynchClock IntSP_Ev Clock Synchronization
- >Light on SP >Back Light on
- HWTestMod IntSP Hardware Test Mode
- Distur.CFC OUT Disturbance CFC
- Brk OPENED IntSP Breaker OPENED
- FdrEARTHED IntSP Feeder EARTHED
3 >Time Synch SP >Synchronize Internal Real Time Clock
5 >Reset LED SP >Reset LED
11 >Annunc. 1 SP >User defined annunciation 1
12 >Annunc. 2 SP >User defined annunciation 2
13 >Annunc. 3 SP >User defined annunciation 3
14 >Annunc. 4 SP >User defined annunciation 4
