3657SD610 Manual
C53000-G1176-C145-4
Appendix A
This appendix is primarily a reference for the experienced user. This section provides
ordering information for the models of this device. Connection diagrams for indicating
the terminal connections of the models of this device are included. Following the
general diagrams are diagrams that show the proper connections of the devices to
primary equipment in many typical power system configurations. Tables with all set-
tings and all information available in this device equipped with all options are provided.
Default settings are also given.
A.1 Ordering Information and Accessories 366
A.2 Terminal Assignments 372
A.3 Connection Examples 374
A.4 Default Settings 377
A.5 Protocol-dependent Functions 380
A.6 Functional Scope 381
A.7 Settings 382
A.8 Information List 392
A.9 Group Alarms 416
A.10 Measured Values 417
