2.1 General
31
7SD610 Manual
C53000-G1176-C145-4
to Enabl. w. comp. (available with compounding). Do not use compounding in lines
with series capacitors!
For the trip circuit supervision set at address 140 Trip Cir. Sup. the number of
trip circuits to be monitored: 1 trip circuit, 2 trip circuits or 3 trip
circuits, unless you omit it (Disabled).
If the device is connected to voltage transformers, set this condition in address 144V-
TRANSFORMER. The voltage dependent functions, such as the directional time over-
current stages or the determination of voltage related measuring values can only be
activated by the device if voltage transformers are connected.
If a power transformer is located within the protected zone, set this condition in
address 143 TRANSFORMER order option). The transformer data themselves are then
polled when parameterizing the general porotection data (see 2.1.4.1).
2.1.1.3 Settings
Addr. Parameter Setting Options Default Setting Comments
103 Grp Chge OPTION Disabled
Enabled
Disabled Setting Group Change Option
110 Trip mode 3pole only
1-/3pole
3pole only Trip mode
112 DIFF.PROTECTION Enabled
Disabled
Enabled Differential protection
122 DTT Direct Trip Disabled
Enabled
Disabled DTT Direct Transfer Trip
124 HS/SOTF-O/C Disabled
Enabled
Disabled Instantaneous HighSpeed/SOTF
Overcurrent
126 Back-Up O/C Disabled
TOC IEC
TOC ANSI
TOC IEC Backup overcurrent
133 Auto Reclose 1 AR-cycle
2 AR-cycles
3 AR-cycles
4 AR-cycles
5 AR-cycles
6 AR-cycles
7 AR-cycles
8 AR-cycles
ADT
Disabled
Disabled Auto-Reclose Function
134 AR control mode Pickup w/ Tact
Pickup w/o Tact
Trip w/ Tact
Trip w/o Tact
Trip w/o Tact Auto-Reclose control mode
136 FREQUENCY Prot. Disabled
Enabled
Disabled Over / Underfrequency Protection
137 U/O VOLTAGE Disabled
Enabled
Enabl. w. comp.
Disabled Under / Overvoltage Protection
139 BREAKER FAILURE Disabled
Enabled
enabled w/ 3I0>
Disabled Breaker Failure Protection
